Pen Type Vibration Meter Smart Sensor AR63C Digital Vibrameter
- 500 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card PayPal
-
Automatic Doypack Seal Machine (insert and sealing machine)
-
Sand Water Filter/Water treatment plants
-
IPX3/IPX4 Hand-held Water Spray Nozzle Test Device IEC 60529
-
IPX5,IPX6 Jet Nozzle of IEC 60529， Brass material
-
Adjustable and multifunctional Spring Impact Hammer IK01-IK07 Level Tester
-
Test probe 43 IEC 61032-Probe 43-Figure 17 Jusdtest
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | SMART SENSOR | Model Number: | AR63C |
Product Description
I.Introduciton:
Vibration meter(also called also called vibration severity) uses Piezoelectric Acceleration Transducer transfer the vibration signal in to electrical signal, analyze the input signals, and show the Acceleration, speed, shift of the vibration.It is widely used in the lines of Power, petrochemical, machinery manufacturing, metallurgy, vehicles, etc
II.Parameter
SPECIFICATION |
|
Vibration Pickup | Piezoelectric Ceramic Accelerometer(shear-type) |
Acceleration | 0.1~199.9m/s2 |
Velocity | 0.1~199.9m/s |
Displacement | 0.001~1.999mm |
Acceleration Frequency Range | 10HZ~1KHZ(LO) 1KHZ~15KHZ(HI) |
Velocity Frequency Range | 10HZ~1KHZ |
Displacement Frequency Range | 10HZ~1KHZ |
Accuracy | ±5%H±2digits |
Singnal Output | AC output |
Auto Switch Range | √ |
Backlight | √ |
Auto Power off | √ |
PACKING |
|
Power | AAA*2 battery |
Product Net Weight | 60g |
Product Size | 150*40*20mm |
Packing | Gift box |
Standard Quantity Per Carton | 40PCS |
Standard Carton Size | 52*40*49cm |
Standard Carton Gross Weight | 15KG |
