HOT SALE! NEW SIGLENT Arbitrary Function Signal Generator SDG1050 50MHz 125MSa/s 16Kpts 48
PRODUCT DESCRIPTION
Main Features:
- Apply DDS technology, double output, adjustable phase, the highest output frequency is 50MHz.
- 125MSa/s sample rate, 14bit vertical resolution, 16Kpts wave length.
- Output 5 types of standard waveform, internally installed 48 types of waveform;
- Internally installed high precision, wide frequency counter, frequency is up to 200MHz.
- Abundant modulation function, sweep-frequency output, pulse train output.
- Standard collocation connection: USB Device, USB Host, support U Disk storage and software upgrading;
- GPIB and LAN port are optional.
- Can connect to SDS1000 series digital oscilloscope perfectly, and support remote command control.
Specification:
Model
SDG1005
SDG1010
SDG1020
SDG1025
SDG1050
highest frequency output
5MHz
10MHz
20MHz
25MHz
50MHz
output channels
2
sample rate
125 MSa/s
wave length
16 Kpts (channel one can choose 512Kpts)
frequency resolution
1μHz
vertical resolution
14 Bit
waveform
Sine wave, square wave , triangular wave , pulse wave ,white noise,48 types of function waveform
Sine wave
1μHz ~ 5MHz
1μHz ~ 10MHz
1μHz ~ 20MHz
1μHz ~ 25MHz
1μHz ~ 50MHz
square wave
1μHz ~ 5MHz
1μHz ~ 10MHz
1μHz ~ 20MHz
1μHz ~ 25MHz
1μHz ~ 25MHz
pulse
1μHz ~ 5MHz
1μHz ~ 10MHz
1μHz ~ 10MHz
1μHz ~ 10MHz
1μHz ~ 10MHz
Ramp
1μHz ~ 300KHz
1μHz ~ 300KHz
1μHz ~ 300KHz
1μHz ~ 300KHz
1μHz ~ 300KHz
Gaussian white noise
5MHz bandwidth(-3dB)
10MHz bandwidth(-3dB)
20MHz bandwidth(-3dB)
25MHz bandwidth(-3dB)
50MHz bandwidth(-3dB)
wave
1μHz ~ 5MHz
1μHz ~ 10MHz
1μHz ~ 10MHz
1μHz ~ 10MHz
1μHz ~ 10MHz
modulation function
AM,FM,PM,ASK,FSK,PWM etc.
other functions
Frequency counter:frequency is up to200MHz
Standard configuration
USB Host & Device
Optional port
GPIB(IEEE-488),LAN
product classify
function/waveform generator
size
widthheightdepth=229mm105mm281mm
Standard Accessories
- One Power Cord that fits the standard of destination county
- One USB Cable
- One User Manual
- One Set Of UltraWave for WIN98/2000/XP arbitrary Waveform Drawing software
Optional Accessories
- BNC Coaxial cable
- GPIB/LAN Interface
