Home > Instruments & Meters > Electronic Instrument > Oscilloscope > The Latest Version ARRIVAL SDG1020 Siglent Arbitrary Signal Function Generator 20M 125 MSa/s Dual Channel

The Latest Version ARRIVAL SDG1020 Siglent Arbitrary Signal Function Generator 20M 125 MSa/s Dual Channel

Name: The Latest Version ARRIVAL SDG1020 Siglent Arbitrary Signal Function Generator 20M 125 MSa/s Dual Channel
Brand: graigar
SKU: 130779679
Availability: InStock

The Latest Version ARRIVAL SDG1020 Siglent Arbitrary Signal Function Generator 20M 125 MSa/s Dual Channel thumbnail-1

The Latest Version ARRIVAL SDG1020 Siglent Arbitrary Signal Function Generator 20M 125 MSa/s Dual Channel photo-1

US$ 340 - 380 MOQ: 1 Piece

Key Specifications

Get Latest Price

Brand Name:

graigar

Model Number:

sdg1020

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name graigar

Model Number sdg1020

The latest version ARRIVAL SDG1020 Siglent Arbitrary Signal Function Generator 20M 125 MSa/s Dual Channel

PRODUCT DESCRIPTION

Features:

Apply DDS technology, double output, adjustable phase, the highest output frequency is 50MHz.
125MSa/s sample rate, 14bit vertical resolution, 16Kpts wave length.
Output 5 types of standard waveform, internally installed 48 types of waveform;
Internally installed high precision, wide frequency counter, frequency is up to 200MHz.
Abundant modulation function, sweep-frequency output, pulse train output.
Standard collocation connection: USB Device, USB Host, support U Disk storage and software upgrading;
GPIB and LAN port are optional.
Can connect to SDS1000 series digital oscilloscope perfectly, and support remote command control.

Specifications:

Model	SDG1005	SDG1010	SDG1020		SDG1025	SDG1050
highest frequency output	5MHz	10MHz	20MHz		25MHz	50MHz
output channels	2
sample rate	125 MSa/s
wave length	16 Kpts (channel one can choose 512Kpts)
frequency resolution	1μHz
vertical resolution	14 Bit
waveform	Sine wave, square wave , triangular wave , pulse wave ,white noise,48 types of function waveform
Sine wave	1μHz ~ 5MHz	1μHz ~ 10MHz	1μHz ~ 20MHz	1μHz ~ 25MHz			1μHz ~ 50MHz
square wave	1μHz ~ 5MHz	1μHz ~ 10MHz	1μHz ~ 20MHz	1μHz ~ 25MHz			1μHz ~ 25MHz
pulse	1μHz ~ 5MHz	1μHz ~ 10MHz	1μHz ~ 10MHz	1μHz ~ 10MHz			1μHz ~ 10MHz
Ramp	1μHz ~ 300KHz	1μHz ~ 300KHz	1μHz ~ 300KHz	1μHz ~ 300KHz			1μHz ~ 300KHz
Gaussian white noise	5MHz bandwidth(-3dB)	10MHz bandwidth(-3dB)	20MHz bandwidth(-3dB)	25MHz bandwidth(-3dB)			50MHz bandwidth(-3dB)
wave	1μHz ~ 5MHz	1μHz ~ 10MHz	1μHz ~ 10MHz	1μHz ~ 10MHz			1μHz ~ 10MHz
modulation function	AM,FM,PM,ASK,FSK,PWM etc.
other functions	Frequency counter:frequency is up to200MHz
Standard configuration	USB Host & Device
Optional port	GPIB(IEEE-488),LAN
product classify	function/waveform generator
size	widthheightdepth=229mm105mm281mm
