New Released Item SIGLENT SHS806 shs 806 60MHz 1GSa/s Handheld Digital Oscilloscope 2Mpts Memory Depth
PRODUCT DESCRIPTION
High-performance oscilloscope
1,Bandwidth:60MHz
2,Real-time sampling rate:1G Sa/s
3,Equivalent sampling rate:50G Sa/s
4,Memory depth:2Mpts
Data recorder function
1,7M internal storage,up to18 hours recording time
2,USB port, up to 3000 hours recording time
3,Record, replay and zoom function supported
High precision multimeter
1,6000 counts display
2,Accurate measurement of DCV, ACV, DCI, ACI
3,Accurate measurement of Resistance, Diode, Capacitance, Continuity
TrendPlot
1,32 measurement trendplot analyzer
2,Scope: 800k points capacity, more than 24 hours recording time
3,Meter:1.6M points capacity 9320 hours recording time at 0.05Sa/s
Oscilloscope Specifications | ||
Model |
SHS806 |
SHS810 |
Bandwidth |
60MHz |
100MHz |
Rise Time |
≤5.8ns |
≤3.5ns |
Real Time Sampling Rate |
1GS/s |
|
Equivalent Sampling Rate |
50GS/s |
|
Vertical Sensitivity |
5mV~100V/div |
|
Time Base Range |
5ns~50s/div |
2.5ns~50s/div |
Scan:100ms~50s/div | ||
Memory Depth |
2M |
|
Triggering |
Edge,Pulse,Video, Slope ,Alternative, |
|
Vertical Resolution |
8bit |
|
Triggering Frequency Counter |
6 digit |
|
Interface |
USB Device,USB Host |
|
Math operation |
+, -, * , /, FFT |
|
Display |
5.7 inches color TFT-LCD, 320*234 |
|
Multimeter Specification | ||
Display |
6000 |
|
Item |
Range |
Accuracy |
DC Voltage |
60mV - 1000V |
1%15digit |
AC Voltage |
60mV –750V |
1%15digit |
DC Current |
60mV -10A |
1%5digit |
AC Current |
60mV -10A |
1%5digit |
Capacitance |
40.00nF |
3%10digit |
400.0nF-400.0uF |
4%5digit |
|
Resistance |
600Ω - 60MΩ |
1%5digit |
Continuity buzzer |
<50Ω |
|
Diode |
0V~2.0V |
|
Trend plot |
1.6M points |
|
Recorder |
7M pionts |
|
Measuring mode |
Manual/Auto |
|
General Feature | ||
Display |
5.7 inches color TFT-LCD, 320*234 |
|
Power Supply |
Charging/Battery |
|
Power mode |
Lithium battery: 7.4V 5000mAh, Battery lasts 5 hours; DC adapter, 100-240V 50/60Hz input, 9V 4A output |
|
Weight |
1.5Kg |
|
Dimension |
163.2mm259.5mm53.3mm |
|
Accessories |
Two passive probes, multimeter pen USB data cable, DC adapter, manual, CD. |
|
