Hot sale Siglent 100mhz Storage Oscilloscope SDS1102CML 1G
PRODUCT DESCRIPTION
100% new, factory packed and never been used. This digital offers reliably and high quality measurement technology for a really good price.
The Siglent 100MHZ Digital Storage Oscilloscope (SDS1102CML) have below applications: design and debuge in electron circuitry; view moment signal; industry controling measure; product quality control; education and trainning; serving and maintaining
Features:
Specification
Model |
SDS1072CML |
SDS1102CML |
SDS1152CML |
Bandwidth |
70MHz |
100MHz |
150MHz |
Channels |
2CH+1EXT |
||
Real time sampling rate |
1GSa/s |
||
Equivalent sampling rate |
50GSa/s |
||
Memory depth |
2Mpts |
||
Rise time |
< 5ns |
< 3.5ns |
< 2.3ns |
Input impedance |
1MΩ 17pF |
||
Time base range |
5.0ns/div-50s/div |
2.5ns/div-50s/div |
|
Scan: 100ms-50s/div | |||
Vertical sensitivity |
2mV-10V/div |
||
Vertical resolution |
8bit |
||
Trigger source |
CH1, CH2, Ext, Ext/5, AC Line |
||
Trigger types |
Edge, Pulse, Video, Slope, Alternative |
||
Math Operation |
+, -, ×, ÷, FFT |
||
Digital filter |
High pass, Low pass, Band pass, Band Stop |
||
Max input voltage |
±400V (DC+AC Pk-Pk), CAT I, CAT II |
||
Internal storage |
2 groups of reference waveform, 20 groups of setting, 10 groups of waveform |
||
External storage |
Bitmap save, CSV save, Waveform save, Setting save |
||
Language |
English, French, German, Russian, Spanish, Simplified Chinese, Traditional Chinese, Portuguese, Japanese, Korean, Italian, Arabic |
||
Interface |
USB Host, USB Device, RS-232, Pass/Fail out |
||
Display |
7 inches(178mm) color TFT(480*234) LCD |
||
Power |
AC 100-240V, 45Hz-440Hz, 50VA Max |
||
PC software |
Can through the computer remote control oscilloscope, extraction waveform analysis data |
||
Remark |
With original source seamless connection, form signal collection, produce integration system |
||
1 x SDS1102CM Oscilloscope
1 x USB Cable
2 x Probes
1 x Power Cord
1 x User Manual
Memory depth of SDS1000CM is 2M.pts
Max recording length: 6Mpts;Max recording time:33.3h
The volume exquisite and it is convenient for carrying
Use Colored TFT LCD, the waveform display is clearer and stable
Screen saver function1 minute to 5 hours
Dual channel-channel bandwidth: 60MHZ-150MHZ
The real time sampling rate is 1GSa/s
Trigger Modes: Edge, Pulse, Video, Slope and Alternative trigger modes
Unique Digital Filter function and Waveform recorder function
Pass/Fail function
Thirty two parameters Auto measure function
Cursor measure covers Manual mode, Track mode and Auto mode
Channel waveform and it?s FFT waveform display on split screen
Pop-up Menu display pattern is more convenient for users using it
Multiple Language User Interface
-
Support Multilingual online help system
