OWON SDS5032E Digital Oscilloscope 2 + 1 Channel 30MHz 250MS/s 10K
US$ 260 - 299
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OWON
Model Number:
SDS5032E
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
OWON SDS7102 100Mhz 8 Inch Digital Storage Oscilloscope 2 Channel 2Gs/sUS$ 413 - 423MOQ: 1 Piece -
OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep MemoryUS$ 668 - 980MOQ: 1 Piece
-
SDS6062 8 Inches TFT 10M Storage 60MH 3 Channels 1GS/S Portable Digital OscilloscopeUS$ 408 - 418MOQ: 1 Piece
-
MSO4012 Digital Oscilloscope 100MHz 2,16 Digital ChannelsUS$ 4,588 - 4,788MOQ: 1 Piece
-
Rigol DS4012 Digital Oscilloscope,100MHz ,2ChannelsUS$ 3,588 - 3,688MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
OWON
Model Number
SDS5032E
OWON SDS5032E digital oscilloscope 2 + 1 channel 30MHz 250MS/s 10K
Item specifics
- Brand Name:
- Owon
- Model Number:
- SDS5032E
Product Description
Main Features - Bandwidth:
30MHz; - Sample rate: 250MS/s;
- 8 inch high definition TFT display;
- Ultra-thin body;
- Pass/Fail function;
- Add/remove measure function,user-defined measure menu.
Application
- Electronic circui debugging Circuit testing
- Design and manufacture
- Education and training
- Automobile maintenance and testing
Specifications
| Model | SDS5032E | SDS6062E | SDS7072E | SDS7102E | SDS7122E | ||
| Bandwidth | 30MHz | 60MHz | 70MHz | 100MHz | 125MHz | ||
| Sample Rate (real time) | 500MS/s | 1GS/s | |||||
| Horizontal Scale (s/div) | 4ns/div-100s/div, step by 1~2~4 |
5ns/div - 100s/div, step by 1 - 2 - 5 |
2ns/div - 100s/div, step by 1 - 2 - 5 |
||||
| Rise Time (at input, typical) | ≤11ns | ||||||
| Channel | 2 + 1 (external) | ||||||
| Display | 8" color LCD, TFT display , 800 × 600 pixels, 65535 colors | ||||||
| Input Impedance | 1MΩ ± 2%, in parallel with 15pF±5pF | ||||||
| Channel Isolation | 50Hz : 100 : 1, 10MHz : 40 : 1 | ||||||
| Max Input Voltage | 400V (PK - PK) (DC+AC, PK - PK) | ||||||
| DC Gain Accuracy | ±3% | ||||||
| Record Length | 10K | 1M (optional 10M) | |||||
| DC Accuracy (average) | Average≥16±(3% reading + 0.05 div) for V | ||||||
| Probe Attenuation Factor | 1X, 10X, 100X, 1000X | ||||||
| LF Respond (AC, -3dB) | ≥10Hz (at input, AC coupling, -3dB) | ||||||
| Sample Rate / Relay Time Accuracy | ±100ppm | ||||||
| Interpolation | sin (x) / x | ||||||
| Interval (T) Accuracy (full bandwidth) | Single : ±(1 interval time + 100ppm × reading + 0.6ns), Average>16 : ±(1 interval time + 100ppm × reading + 0.4ns) | ||||||
| Input Coupling | DC, AC , and GND | ||||||
| Vertical Resolution (A/D) | 8 bits resolution (2 Channels simultaneously) | ||||||
| Vertical Sensitivity | 5mV/div-10V/div (at input) | 2mV/div-10V/div (at input) | |||||
| Trigger Type | Edge, Pulse, Video, Slope, Alternate | ||||||
| Trigger Mode | Auto, Normal, Single | ||||||
| Trigger Level | ±6 divisions from screen center | ||||||
| Line / Field Frequency (video) | NTSC, PAL, and SECAM standard | ||||||
| Cursor Measurement | V, and T between cursors | ||||||
| Automatic Measurement | Vpp, Vavg, Vamp, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Overshoot, Preshoot, Rise Time, Fall Time, Delay A→B↑, Delay A→B↓, +Width, -Width, +Duty, -Duty |
||||||
| Waveform Math | +, -, ×, ÷, FFT | ||||||
| Waveform Storage | 15 waveforms | ||||||
| Lissajous Figure | Bandwidth | Full bandwidth | |||||
| Phase Difference | ±3 degrees | ||||||
| Communication Interface | USB, USB flash disk storage, Pass / Fail, LAN, VGA (optional) | ||||||
| Cymometer | available | ||||||
| Power Supply | 100V - 240V AC, 50/60Hz, CAT 2 | ||||||
| Power Consumption | less than18W | ||||||
| Fuse | 2A, T class, 250V | ||||||
| Battery | not supported | ||||||
| Dimension (W×H×D) | 348 × 170 × 78 (mm) | ||||||
| Weight (without package) | 1.50 kg | ||||||
Accessories
power cord;
CD Rom;
Manual;
USB;
Probe;
Probe Adjust;
Soft bag(optional);
Comparison
| Model No. | Bandwidth | Sample Rate | Record Length | Channel |
| SDS5032E | 30MHz | 500MS/s | 10K | 2+1 |
| SDS6062E | 60MHz | 500MS/s | 1M / optional 10M | 2+1 |
| SDS7072E | 70MHz | 1GS/s | 1M / optional 10M | 2+1 |
| SDS7102E | 100MHz | 1GS/s | 1M / optional 10M | 2+1 |
| SDS7122E | 125MHz | 1GS/s | 1M / optional 10M | 2+1 |
