OWON SDS7102 100Mhz 8 Inch Digital Storage Oscilloscope 2 Channel 2Gs/s

Name: OWON SDS7102 100Mhz 8 Inch Digital Storage Oscilloscope 2 Channel 2Gs/s
Brand: OWON
SKU: 130779391
Availability: InStock

US$ 413 - 423 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

OWON

Model Number:

SDS7102

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name OWON

Model Number SDS7102

OWON SDS7102 digital oscilloscope 2 + 1 channel 100MHz 1GS/s

Product Description

10M record length with highest 3.2GS/s sample rate AutoScale function to simplify

the operation Smart design body with easy workplace Come with SVGA port to

enlarge waveform display 8 inch high definition TFT display (800 x 600 pixels) Super

capacity lithium battery for optional

OWON Oscilloscope SDS7102V/SDS7102 Outstanding feature:

1.100MHz Bandwidth

2.1GS/S Real-sample Rate

3.10M points Record length

4.8 inch color LCD(800X600 Pixels)

5. Autoscale function

6. Display Grid: 10div, Horizontal: 15 div

7. Waveform Storage: 15 waveforms

8. Battery(Optional)

9. Size: 340mmx155mmx70mm(L*H*W)

10. Light Weight: 1.8kg(without battery)

Models in the SmartDS Series

Model	SDS6062	SDS7102	SDS8102	SDS8202	SDS8302	SDS9302

Bandwidth	60MHz	100MHz	100MHz	200MHz	300MHz	300MHz
Sample rate(Real time)	500MS/s	1GS/s	2GS/s	2GS/s	2.5GS/s	3.2GS/s
Horizontal Scale(S/div)	5ns/div~100s/div, step by 1~2~5	2ns/div~100s/div,step by 1~2~5		1ns/div~100s/div, step by 1~2~5
Rise time (at input, typical)	≤ 5.8ns	≤ 3.5ns		≤ 1.7ns	≤ 1.17ns
Channels	Dual
Display	8" color LCD,TFT display,800x600 pixels,65535 colors
Dimension	340mm×155mm×70mm
Weight	1.8kg
