Home > Instruments & Meters > Electronic Instrument > Oscilloscope > OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory

Name: OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory
Brand: OWON
SKU: 130779451
Availability: InStock

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory thumbnail-1

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory thumbnail-2

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory thumbnail-3

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory thumbnail-4

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory thumbnail-5

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory thumbnail-6

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory photo-1

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory photo-2

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory photo-3

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory photo-4

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory photo-5

OWON Digital Storage Oscilloscope SDS8202 200MHz 2GS/s 2channel, 10M Deep Memory photo-6

US$ 668 - 980 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OWON

Model Number:

SDS8202

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OWON

Model Number SDS8202

OWON SDS8202 digital oscilloscope 2 + 1 200MHz 2GS/s

Main Features

- Bandwidth : 60MHz - 300MHz
- Sample rate : 500MS/s - 3.2GS/s
- 10M record length for each channel
- Multi-function : auto-scale, Pass / Fail, and current-measuring
- LAN remote control
- Newly supported SCPI
- Smart design with easy portability
- Large 8 inch 800 x 600 pixels display
- Optional battery available

Application

electronic circuit debugging circuit testing

design and manufacture education and training

automobile maintenance and testing

SPECIFICATION

Model No.	Bandwidth	Sample Rate	Record Length	Channel
SDS6062	60MHz	500MS/s	10M	2+1
SDS7072	70MHz	1GS/s
SDS7102	100MHz	1GS/s
SDS8102	100MHz	2GS/s
SDS8202	200MHz	2GS/s
SDS8302	300MHz	2.5GS/s
SDS9302	300MHz	3.2GS/s

Model		SDS6062	SDS7072	SDS7102	SDS8102	SDS8202	SDS8302	SDS9302
Bandwidth		60MHz	70MHz	100MHz		200MHz	300MHz
Sample Rate		500MS/s	1GS/s		2GS/s		2.5GS/s	3.2GS/s
Horizontal Scale (s/div)		5ns/div to100s/div, step by1~2~5	2ns/div to 100s/div, step by1~2~5		1ns/div to 100s/div, step by1~2~5
Rise Time		≤5.8ns	≤5ns	≤3.5ns		≤1.7ns	≤1.17ns
Display		8”color LCD, 800 x 600 pixels, 65535 colors
Channel		2 + 1 (external)
Record Length		max 10M
Input Coupling		DC, AC, and GND
Input Impedance		1MΩ ± 2%, in parallel with 10pF ± 5pF
Channel Isolation		50MHz : 100 : 1, 10MHz : 40 : 1
Max Input Voltage		400V (PK - PK) (DC + AC, PK - PK)
DC Gain Accuracy		±3%
DC Accuracy		average≥16 : ±(3% reading + 0.05 div) for V
Probe Attenuation Factor		1X, 10X, 100X, 1000X
LF Respond (AC, -3dB)		≥10Hz (at input, AC coupling, -3dB)
Sampling Rate / Relay Time Accuracy		±100ppm
Interpolation		sin (x) / x
Interval (T) Accuracy (full bandwidth)		Single±(1 interval time + 100ppm × reading + 0.6ns); Average>16 : ±(1 interval time + 100ppm × reading + 0.4ns)
Vertical Resolution (A/D)		8 bits resolution (2 channels simultaneously)
Vertical Sensitivity		2mV/div~10V/div
Trigger Type		Edge, Pulse, Video, Slope, Alternate
Trigger Mode		Auto, Normal, Single
Trigger Level		±6 divisions from screen center
Acquisition modes		Sample, Peak Detect, and Average
Line / Field Frequency (video)		NTSC, PAL and SECAM standard
Cursor Measurement		V, and T between cursors
Automatic Measurement		Vpp, Vavg, Vamp, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Overshoot, Preshoot, Rise Time, Fall Time, Delay A→B↑, Delay A→B↓, +Width, -Width, +Duty, -Duty
Waveform Math		, ×, ÷, FFT
Waveform Storage		15 waveforms
Lissajous Figure	Bandwidth	full bandwidth
	Phase Difference	±3 degrees
Communication Interface		USB, USB flash disk storage, Pass / Fail, LAN, VGA (optional), or COM (optional)
Cymometer		available
Power Supply		100V - 240V AC, 50/60Hz, CAT2
Power Consumption		< 24W
Fuse		2A, T class, 250V
Battery (optional)		7.4V, 8000mA
Dimension (W × H × D)		340 × 155 × 70 (mm)
Weight (without package)		1.80 kg
