MSO4012 Digital Oscilloscope 100MHz 2,16 digital channels

MSO/DS4000 Series Digital Oscilloscope

MSO/DS4000 Series is the new mainstream digital scope to meet the customer's applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities.

Feature and Benifits

• Bandwidth 500MHz, 350MHz,200MHz,100MHz

• Sample Rate Analog channel up to 4 GSa/s, Digital Channel up to 1 GSa/s(MSO)

• Standard Memory depth: Analog channel up to 140 Mpts, Digital Channel up to 28 Mpts(MSO)

• 2 or 4 Analog Channels, 16 Digital channels(MSO)

• Waveform capture rate Up to 110,000 waveforms per second,

• Real Time Waveform Record, Replay & Analysis(Std. up to 200,000 frames)

• Lower noise floor, the Min. vertical sensitivity is 1mV/div

• Innovative “UltraVision” technology

• A variety of Trigger functions

• Support serial bus trigger(Std.) and decoding(Opt.) for both analog and digital channels

• Complete Connectivity: USB Host& Device, LAN(LXI-C), VGA, AUX,USB-GPIB(Opt.)

• 9 inch WVGA(800X480), 256 level intensity grading display
