HOT SALE ! Brand New Hantek6052BE USBXI 2CH 50MHz 150MS/s USB Digital Storage Oscilloscope

HOT SALE ! Brand New Hantek6052BE USBXI 2CH 50MHz 150MS/s USB Digital Storage Oscilloscope

PRODUCT DESCRIPTION

Features:

Excellent industrial design-the same anodised aluminium casing as iPad, which is not only beautiful and tasteful but also greatly enhanced the hardness of aluminum alloy surface, and has good heat resistance and strong wearability.

Standard USBXI TM interface, easily inserts into USBXI TM housing to make up a combination instrument.

USB2.0 interface, no external power source required, easy to use.

Be suitable for notebook computer, product line maintenance,be used easily on business.

Dimensions (mm):205(L) x120(W) x35(H), be carried easily.

High performance, 150MS/s real-time sampling, 50MHz Bandwidth.

Operating System: Windows 7, Windows NT, Windows 2000, Windows XP,VISTA.

23 measurement functions, PASS/FAIL Check, be suitable for technical application.

Waveform average, persistence, intensity,invert,addition, subtraction, multiplication, division,X-Y plot.

Save waveform in the following: text file, jpg/bmp graphic file, MS excel/word file.

FFT

One computer can connect many DSO, extend channel easily.

LabviewVBVCDelphiC++Builder Second Design instance.

 Specifications:

Software

Operating system: Windows 7, Windows NT, Windows 2000,Windows XP, VISTA

Second Design

Supply DEMO code(VCCVIVBLABVIEW) and technical support.
