PRODUCT DESCRIPTION
Features:
Dual Channel, 40MHz Bandwidth,
100Ms/s Sample Rate
Probe & USB Cord & SW/CD & Manual are included
Software:
Operating system: Windows98, Windows Me, Windows NT, Windows 2000,
Windows XP, VISTA.
Characteristic:
- USB2.0 interface, no external power source required, easy to use.
- be suitable for notebook computer,product line maintenance,be used easily on business.
- Dimensions (mm):190(L) x100(W) x35(H), be carried easily.
- High performance, 100MS/s real-time sampling, 40MHz Bandwidth.
- Operating System: Windows98,Windows Me, Windows NT, Windows 2000, Windows XP ,VISTA
- 23 measurement functions, PASS/FAIL Check, be suitable for technical application.
- Waveform average, persistence, intensity, invert, addition, subtraction, multiplication, division, X-Y plot.
- Save waveform in the following: text file, jpg/bmp graphic file, MS excel/word file.
- FFT
- One computer can connect many DSO, extend channel easily.
- LabviewVBVCDelphiC++Builder Second Design instance.
Hardware Specification:
Channel |
2 Channels |
Impedance |
1MΩ 25pF |
Coupling |
AC/DC/GND |
Vertical resolution |
8Bit |
Gain range |
10mV-5V, 9Steps |
DC accuracy |
±3% |
Timebase range |
4ns-1h, 38 Steps |
Vertical adjustable |
Yes |
Input protection |
Diode clamping |
X-Y |
Yes |
Autoset |
Yes (30Hz to 40MHz) |
EXT. input |
Yes |
Trigger Mode |
Auto, Normal and Single |
Trigger Slope |
+/- |
Trigger level adjustable |
Yes |
Trigger Type |
Rising edge, falling edge |
Trigger Source |
CH1, CH2, EXT |
Pre/Post trigger |
0-100% |
Buffer size |
10K-32KB/Channel |
Shot bandwidth |
DC to 40MHz |
Max. Sample rate |
100MS/s |
Sampling selection |
Yes |
Waveform Display |
port/line, waveform average, persistence, intensity |
Network |
Open/Close |
Vertical mode |
CH1, CH2, Dual, ADD |
Cursor measurement |
Yes |
Spectrum analyzer | |
Channel |
2 Channels |
Math |
FFT, addition, subtraction, multiplication, division. |
Bandwidth |
40MHz |
Cursor |
Frequency, Voltage |
Data Samples |
10K-32K/Channel |
