Help CenterHOT SALE ! Hantek DSO-2150 150MSa/s 60MHz PC Base USB Digital Storage Oscilloscope Virtual Oscilloscope Dso2150 2CH
Related Products
-
HOT SALE!Portable Oscilloscope Hantek DSO2090 Digital Oscilloscope USB PC Oscilloscope 100MS/s 40MHz DSO-2090US$ 130 - 300MOQ: 1 Piece -
DSO5202BMV Hantek Digital Storage Oscilloscope,2channels 200MHz 1GSa/s, Built-in Video Help, Built-in 2GB Flash Memory CardUS$ 510 - 600MOQ: 1 Piece
-
DSO5102BMV Hantek Digital Storage Oscilloscope,2channels 100MHz 1GSa/s, Built-in Video Help, Built-in 2GB Flash Memory CardUS$ 415 - 530MOQ: 1 Piece
-
DSO5062BMV Hantek Digital Storage Oscilloscope,2channels 60MHz 1GSa/s, Built-in Video Help, Built-in 2GB Flash Memory CardUS$ 415 - 530MOQ: 1 Piece
-
High QualityNew Hantek DSO5202BM Digital Storage Oscilloscope,2channels 200MHz 1GSa/s, 7" Color Display, 2M Record LengthUS$ 460 - 560MOQ: 1 Piece
PRODUCT DESCRIPTION
Features
- Streamline Design,Compact, USB2.0Interface,Free Power,Oscilloscope interface similar to
- desktop,Easy to fly.
- Suitable for notebook computers, product line maintenance, easily on business.
- Small size(Mm): 190 (L) x100 (W) x35 (H),Portable.
- .High refresh rate,High sampling rate, 150MS / sReal-time sampling.
- Software Support: Windows98, Windows Me, Windows NT, Windows 2000, Windows XP, VISTA
- 20I kind of automatic measurement functions, PASS / FAIL CheckFunction,Suitable for
- engineering applications.
- Waveform average,Afterglow,Brightness adjustment,Reverse,Plus,Cut,Ride,Except, X-YShow
- Waveform data can be time-and voltage output toEXCEL, BMP, JPG.
- FFTSpectrum Analysis
- One computer can connect many DSO,Extend channel easily.
- Provide secondary development library, Labview VB VC Delphi C + + BuilderDevelopment
- provides an example
Hardware Specification
Pre/Post trigger |
0-100% |
Buffer size |
10K-32KB/Channel |
Shot bandwidth |
DC to 60MHz |
Max. Sample rate |
150MS/s |
Sampling selection |
Yes |
Waveform Display |
port/line, waveform average, persistence, intensity |
Network |
Open/Close |
Vertical mode |
CH1, CH2, Dual, ADD |
Cursor measurement |
Yes |
Spectrum analyzer | |
Channel |
2 Channels |
Math |
FFT, addition, subtraction, multiplication, division. |
Bandwidth |
60MHz |
Cursor |
Frequency, Voltage |
Data Samples |
10K-32K/Channel |
Accessories |
S/W CD, probes, manual, USB cord |
Channel |
2 Channels |
Impedance |
1MΩ 25pF |
Coupling |
AC/DC/GND |
Vertical resolution |
8Bit |
Gain range |
10mV-5V, 9Steps |
DC accuracy |
±3% |
Timebase range |
4ns-1h, 38 Steps |
Vertical adjustable |
Yes |
Input protection |
Diode clamping |
X-Y |
Yes |
Autoset |
Yes (30Hz to 60MHz) |
EXT. input |
Yes |
Trigger Mode |
Auto, Normal and Single |
Trigger Slope |
+/- |
Trigger level adjustable |
Yes |
Trigger Type |
Rising edge, falling edge |
