PRODUCT DESCRIPTION
Features
- USB2.0 interface, no external power source required, easy to use.
- be suitable for notebook computer,product line maintenance,be used easily on business.
- Dimensions (mm):190(L) x100(W) x35(H), be carried easily.
- High performance, 250MS/s real-time sampling,100MHz Bandwidth.
- Operating System: Windows98,Windows Me, Windows NT, Windows 2000, Windows XP ,VISTA
- 23 measurement functions, PASS/FAIL Check, be suitable for technical application.
- Waveform average, persistence, intensity, invert, addition, subtraction, multiplication, division, X-Y plot.
- Save waveform in the following: text file, jpg/bmp graphic file, MS excel/word file.
- FFT
- One computer can connect many DSO, extend channel easily.
- LabviewVBVCDelphiC++Builder Second Design instance.
Technical Specifications
Channel |
2 Channels |
Bandwidth |
100MHz |
Max. Sample rate |
250MS/s |
Impedance |
1M? 25pF |
Coupling |
AC/DC/GND |
Vertical resolution |
8Bit |
Gain range |
10mV-5V, 9Steps |
DC accuracy |
±3% |
Timebase range |
4ns-1h, 38 Steps |
Vertical adjustable |
Yes |
Input protection |
Diode clamping |
X-Y |
Yes |
Autoset |
Yes (30Hz to 100MHz) |
EXT. input |
Yes |
Trigger Mode |
Auto, Normal and Single |
Trigger Slope |
+/- |
Trigger level adjustable |
Yes |
Trigger Type |
Rising edge, falling edge |
Trigger Source |
CH1, CH2, EXT |
Pre/Post trigger |
0-100% |
Buffer size |
10K-512KB/Channel |
Shot bandwidth |
DC to 100MHz |
Sampling selection |
Yes |
Waveform Display |
port/line, waveform average, persistence, intensity |
Network |
Open/Close |
Vertical mode |
CH1, CH2, Dual, ADD |
Cursor measurement |
Yes |
Math |
FFT, addition, subtraction, multiplication, division. |
Cursor |
Frequency, Voltage |
Data Samples |
10K-512K/Channel |
Accessories |
S/W CD, probes, manual, USB cord |
Operating system: Operating system: Windows98, Windows Me, Windows NT, Windows 2000,Windows XP, VISTA.
Supply DEMO code (VC, CVI, VB, LABVIEW) and technical support.
Include Accessories:
1.The Digital Oscilloscope DSO 2250
2.The Software CD Package
3.The Operation Manual in English
4.High Frequency 1:10 Probe X 2
5.The USB cord.
Packing list:
1 * DSO-2250
1 * USB Cord
2 * probe
1 * CD & Manual
