DSO4202C Digital Oscilloscope,High-frequency Oscilloscope,Lower Power Consumption DSO4202C
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Graigar
Model Number:
DSO4202C
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Oscilloscope Probe CP-3601R Bandwidth: DC~600MHz Fix X10; Readout Function EN61010-031, 600V CAT INegotiableMOQ: 1 Piece -
Oscilloscope Probe CP-3501Rpro Bandwidth: 500 MHz Cursor Readout: O Max. Working Voltage: CAT I 600V CAT II 300V Division RatiNegotiableMOQ: 1 Piece
-
Oscilloscope Probe CP-3351R Bandwidth 350MHz Read Out Function, X10 FIXNegotiableMOQ: 1 Piece
-
Oscilloscope Probe CP-3308R 100:1 Scope Probe Bandwidth:300MHz Read Out Function Division Ratio x 100NegotiableMOQ: 1 Piece
-
Oscilloscope Probe CP-3101R Max.Working Voltage: 600V Dc;1000V Peak;300V Rms Have Cursor Readout Bandwidth: 100MHzNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Graigar
Model Number
DSO4202C
DSO4202C Digital Oscilloscope,High-frequency Oscilloscope,Lower Power Consumption DSO4202C
Feature:
- 2 Channel Digital Oscilloscope + Arbitrary/Function Waveform Generator + Synchronizing Signal + External Trigger;
- The Keys for osilloscope and waveform generator is seperated for convenient to operate it simultaneously;
- Large and clear display (7 inch 64K color LCD display, Resolution 800x480), more clear and realistic waveform;
- Oscilloscope: 1GSa/s Sample Rate, 200/100/70MHz Bandwidth, more than 20 kinds of auto measurement functions;
- Powerful Trigger Function: Edge, Video, Pulse, Slope, Over time, Alternative;
- Arbitrary/Function Waveform Generator: 25MHz, 12 bits resolution, 200MHz DDS, Arbitrary wave/square wave/sine wave/triangle wave/trapezoidal wave/pulse wave/DC is easy to simulate transducer.
- Support SD card, VGA function (optional);
- Integrated USB Host, Support USB disk storage, USB interface/SD card system update.
-
Display Type 7 inch 64K color TFT (diagonal liquid crystal) Display Resolution 800 horizontal by 480 vertical pixels Display Contrast Adjustable (16 gears) with the progress bar Probe Compensator Output Output Voltage( typical) About 5Vpp into ≥1MΩ load Frequency(typical) 1kHz Power Supply Supply Voltage 100-120VACRMS(±10%), 45Hz to 440Hz, CATⅡ 120-240VACRMS(±10%), 45Hz to 66Hz, CATⅡ Power Consumption <30W Fuse 2A, T rating, 250V Environmental Temperature Operating: 32℉ to 122℉ (0℃ to 50℃); Nonoperating: -40℉ to 159.8℉ (-40℃ to +71℃) Cooling Method Convection Humidity +104℉ or below (+40℃ or below): ≤90% relative humidity; 106℉ to 122℉ (+41℃ to 50℃): ≤60% relative humidity Altitude Operating: Below 3,000m (10,000 feet); Nonoperaring: Below 15,000m(50,000 feet) Mechanical Size Length 385mm, Width 200mm, Height 245mm Weight 3.5KG(with Packing); 2.08KG(without Packing) Shawn
