Home > Instruments & Meters > Meter for Electricity > Multimeter > High-accuracy 0.015% DCV Digital True RMS Bench Type Multimeter USB RS232 AC110-240V Max. Display 199999 UT805A Tester

High-accuracy 0.015% DCV Digital True RMS Bench Type Multimeter USB RS232 AC110-240V Max. Display 199999 UT805A Tester

High-accuracy 0.015% DCV Digital True RMS Bench Type Multimeter USB RS232 AC110-240V Max. Display 199999 UT805A Tester thumbnail-1
High-accuracy 0.015% DCV Digital True RMS Bench Type Multimeter USB RS232 AC110-240V Max. Display 199999 UT805A Tester photo-1
US$ 500 - 540 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Uni-Trend
Model Number:
UT805A
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Uni-Trend
Model Number UT805A
Operating Temperature -40 °C ~ 1000 °C
Dimensions 685x370x325mm

Specifications

High-accuracy 0.015% DCV Digital True RMS Bench Type Multimeter USB RS232 AC110-240V Max. Display 199999 UT805A Tester

High-accuracy 0.015% DCV Digital True RMS Bench Type Multimeter USB RS232 AC110-240V Max. Display 199999 UT805A Tester





Short review UNI-T UT805A.Bench type digital multimeter which measures AC/DC voltage, AC/DC current, resistance, frequency, capacitance, temperature and can be used for continuity test.

This UNI-T UT805A bench type digital multimeter is designed for measuring AC/DC current, AC/DC voltage, resistance, capacitance, frequency, temperature and can be used for continuity and diode tests.

UNI-T UT805A Bench Type Digital Multimeter Features

  • Measurement functions:
    • AC/DC voltage
    • AC/DC current
    • capacitance
    • resistance
    • frequency
    • continuity test
  • Auto ranging
  • Data hold
  • Low battery indication

UNI-T UT805A Bench Type Digital Multimeter Technical Specifications

Display 199999 digit LCD, backlight, 128 × 28 mm
DC voltage Range 200 mV / 2 V / 20 V / 200 V / 750 V
Accuracy ±(0.015%+3)
AC voltage Range 2 V / 20 V / 200 V / 1000 V
Accuracy ±(0.2%+100)
DC current Range 2 mA / 20 mA / 200 mA / 1 A / 10 A
Accuracy ±(0.03%+10)
AC current Range 20 mA / 200 mA / 1 A / 10 A
Accuracy ±(0.3%+100)
Resistance Range 200 Ω / 2 kΩ / 20 kΩ / 200 kΩ / 2 MΩ / 20 MΩ
Accuracy ±(0.02%+6)
Capacitance Range 6 nF / 60 nF / 600 nF / 6 µF / 60 µF / 600 µF / 6 mF
Accuracy ±(2%+5)
Frequency Range 10 Hz ~ 60 MHz
Accuracy ±(0.1%+3)
Temperature Range -40 °C ~ 1000 °C
Accuracy ±(1%+ 10)
Power AC 220 V / 50 Hz
Dimensions 300 × 245 × 105 mm
Weight 2.4 kg

UNI-T UT805A Bench Type Digital Multimeter Package Contains

  • Multimeter UNI-T UT805A (1 pc.)
  • Test lead (1 pc.)
  • Test line (1 pc.)
  • Alligator clip (1 pc.)
  • Multi-purpose socket (1 pc.)
  • RS232C interface cable (1 pc.)
  • USB interface cable (1 pc.)
  • Software (1 pc.)
  • AC 220 V power cord (1 pc.)
  • User manual (1 pc.)High-accuracy 0.015% DCV Digital True RMS Bench Type Multimeter USB RS232 AC110-240V Max. Display 199999 UT805A Tester
