Home > Instruments & Meters > Meter for Electricity > Multimeter > UNI-T UT803 UT-803 Bench Top Digital Multimeter Volt Amp Ohm Capacitance Temp Tester

UNI-T UT803 UT-803 Bench Top Digital Multimeter Volt Amp Ohm Capacitance Temp Tester

Name: UNI-T UT803 UT-803 Bench Top Digital Multimeter Volt Amp Ohm Capacitance Temp Tester
Brand: Uni-Trend
SKU: 130769321
Availability: InStock

UNI-T UT803 UT-803 Bench Top Digital Multimeter Volt Amp Ohm Capacitance Temp Tester thumbnail-1

UNI-T UT803 UT-803 Bench Top Digital Multimeter Volt Amp Ohm Capacitance Temp Tester thumbnail-2

UNI-T UT803 UT-803 Bench Top Digital Multimeter Volt Amp Ohm Capacitance Temp Tester photo-1

UNI-T UT803 UT-803 Bench Top Digital Multimeter Volt Amp Ohm Capacitance Temp Tester photo-2

US$ 180 - 200 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Uni-Trend

Model Number:

UT803

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Uni-Trend

Model Number UT803

Measuring Current Range 600/6000/60mA/600/10A

Measuring Voltage Range 600mV/6V/60V/600V/1000V

Measuring Resistance Range 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ

Measuring Capacitance Range 6/60/600nF/6/60/600/6

Dimensions 685 x 370 x 325mm

Specifications

1KV/10A,Temp.:-40-1000C, 19999 Max. display , Digital Bench Type Digital Multimeter UT802

1KV/10A,Temp.:-40-1000C, 19999 Max. display , Digital Bench Type Digital Multimeter UT802

SPECIFICATIONS

Basic Functions	Range	Best Accuracy
DC Voltage	600mV/6V/60V/600V/1000V	±(0.3%+2)
AC Voltage	600mV/6V/60V/600V/1000V	±(0.6%+5)
DC Current	600µA/6000µA/60mA/600mA/10A	±(0.5%+3)
AC Current	600µA/6000µA/60mA/600mA/10A	±(1%+5)
Resistance	600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ	±(0.5%+2)
Capacitance	6nF/60nF/600nF/6µF/60µF/600µF/6mF	±(2%+5)
Temperature (^oC)	-40°C ~ 1000°C	±(1%+3)
Temperature (^oF)	-40°F ~ 1832°F	±(1.5%+5)
Frequency	6kHz/60kHz/600kHz/6MHz/60MHz	±(0.1%+3)
Special Functions
Fused 10A Range		√
Auto Ranging		√
Voltage & Current : AC+DC Measurement		√
AC Voltage Frequency	100kHz True RMS	√
Diode		√
Continuity Buzzer		√
Transistor		√
Max/Min Mode		√
Data Hold		√
RS232C		√
USB		√
Display Backlight		√
Full Icon Display		√
Sleep Mode		√
Low Battery Display		√
Input Impedance for DC Voltage Measurement	600mV Range Around 3GΩ All Other Ranges: 10MΩ	√
Max. Display	5999	√

GENERAL CHARACTERISTICS

Power	AC220V/50Hz or 1.5V Battery(R14) x 6
LCD Size	128 x 28mm
Product Colour	Red and Grey
Product Net Weight	2.4kg
Product Size	310 x 240 x 105mm
Standard Accessories	Test Lead, AC220V Power Cord,English Manual, Point Contact, Temperature Probe, Alligator Clip,Multi-Purpose Socket, RS232C Interface Cable, USB Interface Cable, Software
Optional Accessories*	1.5V Battery(R14) x 6
Standard Individual Packing	Gift Box
Standard Quantity Per Carton	4pcs
Standard Carton Measurement	685 x 370 x 325mm (0.083 CBM Per Standard Carton)
Standard Carton Gross Weight	15kg
