Specifications
MASTECH MS8218 High ACCURACY 50000 COUNTS DMMMASTECH MS8218 High ACCURACY 50000 COUNTS DMM
FEATURES
50000 counts measurement
Auto/Manual Range
ACV and DCV measurements reach up to 1000V
DC measurement accuracy reaches up to 0.03%
0.01Ω resistance and 1µV voltage resolution
Voltage/Current Linear frequency measurement
Logic frequency/duty cycle measurement
Capacitance measurement from 0.01nf to 5000µF
AC/DC true RMS measurement/dBm measurement
MAX/MIN/MAX-MIN and Relative value measurement
Data hold/Back light/Auto off
RS-232C infrared interface and PC Windows software
Software calibrates automatically
Full overload protection
Indication for battery low
Secondary injection molding case
Insulating performance reaching 1000V CATIII
SPECIFICATIONS
ACV/DCV+ACV: 50mV/500mV/5V/50V/500V/1000V +0.5%
DCV: 50mV/500mV/5V/50V/500V/1000V +0.03%
AC Current/DC Current + AC Current: 500µA/5000µA/50mA/500mA/5A +0.75%, 10A+0.15%
DC Current: 500µA/5000µA/50mA/500mA/5A/10A +0.15%
Resistance: 500Ω/5kΩ/50kΩ/500kΩ/5MΩ+0.1%, 50MΩ+0.5%
Capacitance: 50nF/500nF/5µF/50µF+1%, 500µF/5000µF+2%
Diode: 2.5V+1%
Duty cycle: 5Hz ~ 500kHz
Range: 10% ~ 90%
Logic frequency: 5Hz ~ 5MHz+0.006%, Vpp 2 ~ 5V square wave
Linear frequency: 10Hz ~ 200kHz+0.006%
Sensitivity: lowest 100mV
Display: LCD size 44mm x 70mm
Weight: Approx. 600g
Size: 200mm*100mm*40mm
