Cheap Mastech MS8226T Auto Ranging Digital Multimeters True RMS

Name: Cheap Mastech MS8226T Auto Ranging Digital Multimeters True RMS
Brand: MASTECH
SKU: 130768221
Availability: InStock

US$ 59 - 68 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

MASTECH

Model Number:

MS8226T

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name MASTECH

Model Number MS8226T

Operating Temperature -20℃-1000℃

Specifications

Cheap Mastech MS8226T Auto Ranging Digital Multimeters True RMS

Specifications:

DCV: 0 - 400mV - 4V - 40V - 400V -1000V +/- 0.5%
ACV: 0 - 400mV - 4V - 40V +/- 0.8%, 400V - 700V +/- 1.0% True RMS
DCA: 0 - 400uA - 4,000uA +/-1.2%, - 40mA - 400mA -10A +/- 2.0%
ACA: 0 - 400uA - 4,000uA +/- 1.5%, -10A +/- 3.0%
Frequency: 5Hz - 50 KHz - 5MHz
Resistance : 0 ?400 - 4k - 40k - 400k - 4M +/- 1.2%, - 40M ohm +/- 2.0%
Duty: 0.1 - 99.9%
CAP: 0 - 5nF - 50nF - 500nF - 5uF - 50uF - 100uF +/- 2.0%
Temp: Shows in Celsius .-20C to 1,000C +/- 3.0%; -4F to 1832F
Relative value measurement
Manual/Auto range select
RS232 series port
Over load indication.
Software included.
Software sampling time: 3 times per second
Audible continuity: < 30 ohm
Diode test: 10mA, 6.0V
Display: 3 3 / 4 digits with max of 3999
Back Light for reading in dark
Battery: 9V x 1,NEDA 1604 / 6F22
Size: (mm) 195 X 92 X 43
Weight:> (Lbs) 1.98

Advantage:
True RMS 3 3/4 digits of auto ranging multimeter is a full features meter for all purposes.
IT meets IEC-1010-1 ,1000V CAT III standards. Pollution degree is 2.
It comes in a nice ABS plastic case with windows software for RS232 data download
Creative design of elegance
RS-232C interface to computer
Auto/Manual ranging
Full protection on all ranges
High safety design with back-up stand

Package Content: CD software, RS232 cable, test leads, Temperature probe, manual book
