Mastech MS8240D Digital Multimeter

Mastech MS8240D Digital Multimeter thumbnail-1
Mastech MS8240D Digital Multimeter photo-1
US$ 109 - 135 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MASTECH
Model Number:
MS8240D
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name MASTECH
Model Number MS8240D
Dimensions 205mmx102mmx58mm

Specifications

Mastech MS8240D Digital Multimeter

Free Shipping Mastech MS8240D Digital Multimeter



Feature
♦AutoRange and Maual Range
♦DATA HOLD function
♦MAX/MIN value measurement
♦Full Overload protection
♦Relative measurement
♦Back Light
♦Low battery indication
♦Auto Power off
♦LPF function
♦Continnuity Test
♦Diode Test
♦Peak value Measurement
♦USB interface


 Specification             MS8240D
Function Range Accuracy
DC Voltage 220mV
2.2V/22V/220V/2200V		 ±(0.05% + 3 )
±(0.1% + 3 )
AC Voltage 220mV/2.2V/22V/220V/700V(50HZ)
220mV/2.2V/22V/220V/700V(2KHZ)
 		 ±(0,8% + 4 )
±(2.5% + 3 )
DC Current 220uA/2.2mA/22mA
220mA/10A		 ±(1.0% + 4 )
±(1.0% + 4 )
AC Current 220uA/2.2mA/22mA
220mA/10A		 ±(1.5% + 3 )
±(1.8% + 3 )
Resistance 220Ω/2.2KΩ/22KΩ/220KΩ
2.2MΩ/22MΩ/220MΩ		 ±(0.8% + 2 )
±(1.0% + 2 )
Capacitance
 		 22nF/220nF/2.2uF/220uF
2.2mF/22mF/220mF		 ±(2.5% + 3 )
±(2.5% + 3 )
Frequency 1Hz~220MHz ±(0.2% + 3 )
Duty 1% to 99% ±(0.2% + 3 )
Counts 22000
Operating temperature & Humidity 0~40(32~104)&<80%RH
Storage temperature & Humidity -10~50(14~122)&<70%RH
Power Supply 1.5V Battery (AA Type)x4
Dimensions 205mmx102mmx58mm
Weight Approx.390g



Mastech MS8240D Digital Multimeter
