Mastech MS8240D Digital Multimeter
USD $109 - $135
/ Piece
5 Pieces(Min.Order)
- 100 Piece / Pieces per Month
- ShenZhen
- T/T Credit Card PayPal
You May Like
-
Mastech MS8226 True RMS Auto Ranging DMM Digital Multimeter
-
Mastech MS8250B Autoranging Meter Digital Multimeters
-
Mastech MS8250C Autoranging Digital Multimeter Wire Line Telephone Tracker
-
MAS830L Mini Digital Multimeter
-
Digital Multimeter MASTECH MAS838
-
MASTECH NEW MS8232A Mini Auto range Digital Multimeter Non-contact voltage detection DMM
Product Details
| Place of Origin | Guangdong, China | Brand Name | MASTECH | |
| Model Number | MS8240D | Dimensions | 205mmx102mmx58mm |
Product Description
Specifications
Mastech MS8240D Digital MultimeterFree Shipping Mastech MS8240D Digital Multimeter
Feature
♦AutoRange and Maual Range
♦DATA HOLD function
♦MAX/MIN value measurement
♦Full Overload protection
♦Relative measurement
♦Back Light
♦Low battery indication
♦Auto Power off
♦LPF function
♦Continnuity Test
♦Diode Test
♦Peak value Measurement
♦USB interface
| Specification | MS8240D | |
| Function | Range | Accuracy |
| DC Voltage | 220mV 2.2V/22V/220V/2200V | ±(0.05% + 3 ) ±(0.1% + 3 ) |
| AC Voltage | 220mV/2.2V/22V/220V/700V(50HZ) 220mV/2.2V/22V/220V/700V(2KHZ) | ±(0,8% + 4 ) ±(2.5% + 3 ) |
| DC Current | 220uA/2.2mA/22mA 220mA/10A | ±(1.0% + 4 ) ±(1.0% + 4 ) |
| AC Current | 220uA/2.2mA/22mA 220mA/10A | ±(1.5% + 3 ) ±(1.8% + 3 ) |
| Resistance | 220Ω/2.2KΩ/22KΩ/220KΩ 2.2MΩ/22MΩ/220MΩ | ±(0.8% + 2 ) ±(1.0% + 2 ) |
| Capacitance | 22nF/220nF/2.2uF/220uF 2.2mF/22mF/220mF | ±(2.5% + 3 ) ±(2.5% + 3 ) |
| Frequency | 1Hz~220MHz | ±(0.2% + 3 ) |
| Duty | 1% to 99% | ±(0.2% + 3 ) |
| Counts | 22000 | |
| Operating temperature & Humidity | 0~40(32~104)&<80%RH | |
| Storage temperature & Humidity | -10~50(14~122)&<70%RH | |
| Power Supply | 1.5V Battery (AA Type)x4 | |
| Dimensions | 205mmx102mmx58mm | |
| Weight | Approx.390g | |
