MT-1232 3 3/4 Autorange Digital Multimeter Auto range, Frequency/Capacitance/Temperature/DMM All in 1.

Counter

5999

Digits

3 5/6

Panel size

70×50mm, 33mm high figure

Backlight

N

Analog bargraph

Y

Auto/Manual ranging

Both

DC (V)

600mV/6V/60V/600V ±(0.5%+4d)

1000V ±(1.0%+6d)

***

AC(V)

6/60/600V ±(0.8%+10d)

750V ±(1.0%+10d)

DC(A)

600μA/6000μA ±(1.0%+10d)

60/600mA ±(1.0%+10d)

6A/10A ±(1.2%+10d)

AC(A)

600μA/6000μA ±(1.5%+10d)

60/600mA ±(1.5%+10d)

6A/10A ±(2.0%+15d)

Resistance(Ω)

600Ω ±(0.8%+5d)

6/60/600K/6MΩ ±(0.8%+4d)

60MΩ ±(1.2%+10d)

***

Frequency(Hz)

100/1000Hz ±(0.5%+4d)

10K/100KHz ±(0.5%+4d)

1M/20MHz ±(0.5%+4d)

Capacitance(μF)

40nF±(5%+30d)

400nF/4μF/40μF±(3.5%+8d)

200μF±(5.0%+10d)

Temperature(C)

(-20C~400C) ±1.0+50d

(400C~1000C) ±1.5+15d

Temperature (F)

(0F~750F) ±(1.0+5d)

(750F~1832F) ±(1.5+5d)

Continuity with beeper

Y

Diode test

Y

Transistor test

Y

Display hold

Y

USB/RS232 interface

RS232

Automatic power off

Y

Low battery indication

Y

EN61010-1 CAT II /CAT III

1000VDC/750VAC

Bettery

1.5V AAA×2

Size (D×W×H)mm

192×95×48

Weight (g)

390g

Individual Packing

Color box
