MASTECH MS5308 AutoRange LCR Tester
This MS5308 LCR digital bridge meter is a professional instrument for measuring inductance, capacitance and resistance. It has many features, such as automatic identification, automatic measurement range, high measurement accuracy and speed, wide measuring range and so on.
An ordinary multimeter only provides DC mode for resistance measurement, while this MS5308 provides both AC and DC measurement modes. A variety of test frequencies up to 100Khz can be provided for inductance, capacitance and resistance in AC mode to meet the actual needs better.
Specifications:
Auto LCR smart check and measurement
19,999/1,999 dual LCD display
Series/Parallel modes are selectable
LsLp/Cs/Cp with D/Q/θ/ESR parameters
Support DCR mode
Five different test frequency are available
100/120/1k/10k/100k Hz
Test rang( ex.F=1K Hz)
L: 200uH~~2000H<br/>C:2000pF~~2.0mF
R:20.000Ω~~200.0MΩ
PowerSupply:1.5×8 AA battery and 1×1604A6LR6(9V) (not included)
Dimension: 224mm×172mm×59mm
Package Contents:
MS5308 LCR digital bridge meter
Kelvin test clip (one pair)
Upper computer program CD
External power supply
SMD test probe
IR data line
