MS2308 Intelligent advanced Earth Resistance Tester,clamp earth resistance tester with usb communication

3 pole & 4 pole earthing-resistance test

Test voltage: AC 20V/48V

√

√

√

Test frequency: 94Hz/105Hz/111Hz/128Hz/AFC

√

√

94Hz/128Hz

Earthing-resistance range

0.02~300k

0.1  ~ 30k

0.1  ~20k

Selective mode

(3 pole +     /

4 pole+     )

Test voltage: AC 20V/48V

√

√

Test frequency: 94Hz/105Hz/111Hz/128Hz/AFC

√

√

Earthing-resistance range

0.02~20k

0.1~10k

Non-auxiliary-polar

mode (      )

Test voltage: AC48V

√

Test frequency: 94Hz/105Hz/111Hz/128Hz/AFC

√

√

Earthing-resistance range

0.02~150

0.1~150

2 pole R~

Test voltage: AC20V

√

√

√

Test frequency: 94Hz/105Hz/111Hz/128Hz/AFC

√

√

94Hz/128Hz

Earthing-resistance range

0.02~ 300k

0.1 ~ 30k

0.1~20k

2 pole /4pole R

Test voltage: DC20V

√

√

Earthing-resistance range

0.02~ 3k

0.1 ~ 3k

Interfering voltage

/current/frequency

Interfering voltage: 1~50V DC/AC

√

√

√

Interfering frequency: 16Hz~400Hz

√

√

√

Interfering current: 20mA~2A

√

√

Soil resistivity ρ

Test voltage: AC20V/48V

√

√

√

Test frequency: 94Hz/105Hz/111Hz/128Hz/AFC

√

√

94Hz/128Hz

Range: 0.02·m~1000k  ·m

√

√

√

RK(wire compensation)

Test voltage: AC20V/48V

√

√

√

Test frequency: 94Hz/105Hz/111Hz/128Hz/AFC

√

√

94Hz/128Hz

Range:

0.02~30

0.1~30

0.1~30

Test current

≤ 250 mA

≤ 100 mA

≤ 100 mA

Data storage

√

√

√

USB communication

√

√

√
