Digital Earth Ground Resistance Voltage Meter Tester 100 Groups Data Storage 1-4K Ohm 50V AC HYELEC MS2302

Digital Earth Ground Resistance Voltage Meter Tester 100 Groups Data Storage 1-4K Ohm 50V AC HYELEC MS2302 thumbnail-1
Digital Earth Ground Resistance Voltage Meter Tester 100 Groups Data Storage 1-4K Ohm 50V AC HYELEC MS2302 thumbnail-2
Digital Earth Ground Resistance Voltage Meter Tester 100 Groups Data Storage 1-4K Ohm 50V AC HYELEC MS2302 thumbnail-3
Digital Earth Ground Resistance Voltage Meter Tester 100 Groups Data Storage 1-4K Ohm 50V AC HYELEC MS2302 photo-1
Digital Earth Ground Resistance Voltage Meter Tester 100 Groups Data Storage 1-4K Ohm 50V AC HYELEC MS2302 photo-2
Digital Earth Ground Resistance Voltage Meter Tester 100 Groups Data Storage 1-4K Ohm 50V AC HYELEC MS2302 photo-3
US$ 92 - 99 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HYELEC
Model Number:
MS2302
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HYELEC
Model Number MS2302
Display Type Digital Only
Measuring Range 0Ω~4.00kΩ
Testing Voltage 0V~200V(50~60Hz)
Accuracy Class other
Operating Temperature Nomal
Dimensions 180mm x 140mm x65mm

Digital Earth Ground Resistance Voltage Meter Tester 100 groups Data Storage 1-4K ohm 50V AC HYELEC MS2302



 Digital Earth Ground Resistance Voltage Meter Tester 100 groups Data Storage 1-4K ohm 50V AC HYELEC MS2302





MS2302 DIGITAL EARTH RESISTANCE TESTER

Specifications

RANGE

ACCURACY

RESOLUTION

Earth ground Resistance

0Ω~29.99Ω

±(2%+6dgt)

0.01Ω

30Ω~99.9Ω

±(3%+3dgt)

0.1Ω

100Ω~999Ω

±(3%+3dgt)

1Ω

1.00kΩ~4.00kΩ

±(3%+3dgt)

10Ω

Earth voltage

0V~200V(50~60Hz)

±(1%+5dgt))

0.1V

Features

Digital Display & Analog Bars Display

2 Pole and 3 Pole Mode

Earth Resistance By Constant Current Inverter 800Hz/3mA

MAX/MIN/AVG/REL Measurement Functions

Data Logging:100 group

Display Back Light

Low Battery Indication

Auto Power Off

GENERAL

Power Supply

6x1.5v AA batteries(not included this order)

Product Size

180mm x 140mm x65mm

Product Weight

Approx. 950g

Safety Rating

CE CAT.III 1000V RoHS













































Digital Earth Ground Resistance Voltage Meter Tester 100 groups Data Storage 1-4K ohm 50V AC HYELEC MS2302Digital Earth Ground Resistance Voltage Meter Tester 100 groups Data Storage 1-4K ohm 50V AC HYELEC MS2302Digital Earth Ground Resistance Voltage Meter Tester 100 groups Data Storage 1-4K ohm 50V AC HYELEC MS2302
