HYELEC MS5203 Digital Insulation Resistance Tester Multimeter Megger 0.01 Mohm to 10.00 Gohm HV meter 50V-1000V output
Source Output Voltage |
Measuring Range |
|||
Insulation tests |
50V(0 %~+20%) |
0.01MΩ~50MΩ±(3%+5) |
||
100V( 0%~+20%) |
0.01MΩ~100MΩ±(3%+5) |
|||
250V( 0%~+20%) |
0.01MΩ~250ΩM±(3%+5) |
|||
500V( 0%~20%) |
0.01MΩ~500MΩ±(3%+5) 1.00GΩ~5.00GΩ±(5%+0.1GΩ) |
|||
1000V( 0%~+20%) |
5.00GΩ~10.00GΩ±(10%+0.2GΩ) |
|||
Short circuit current |
1.8mA |
|||
Multimeter functions |
DC Voltage Test |
0.1~1000V±0.5% |
||
AC Voltage Test |
0.1~50V±1% |
|||
Continuity Test |
0.01Ω~200Ω±0.5% |
|||
|
Features |
l Auto Calculate PI and DAR l Store /Load Function l Compare function l Auto discharge for capacitive load l Timer Function for insulation test l Lock function for insulation test l Low Battery Indication l DCV and ACV Test l Continuity test l Auto power Off l Digital and analog display |
|||
General |
Power Supply |
6x1.5V AA batteries(not included this order ) |
||
Product Size |
180mm x 140mm x65mm |
|||
Product Weight |
Approx. 950g |
|||
Safety Rating |
CE CAT.III 1000V CAT IV 600V RoHS |
|||
Edited by sam
