HYELEC MS5910 RCD Loop Tester Multimeter for GFCI Loop Resistance Testing

Name: HYELEC MS5910 RCD Loop Tester Multimeter for GFCI Loop Resistance Testing
Brand: HYELEC
SKU: 130767291
Availability: InStock

US$ 96 - 104 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

HYELEC

Model Number:

MS5910

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name HYELEC

Model Number MS5910

Display Type Digital Only

Measuring Range other

Testing Voltage 0~440V ±(3%+3V)

Accuracy Class ohter

Operating Temperature 0° C~40° C

Dimensions 180mm x 140mm x65mm

SPECIFICATIONS
	RANGE	ACCURACY	RESOLUTION
Tripping time	x1 IΔN300(slow 500ms) x5 IΔN40ms(slow 150ms)	±3ms	0.1ms
Tripping Current	(0.2-1.1)IΔN	±0.1IΔN	0.5IΔN
Contact Voltage	0~99.9V	±(10%+0.2V)	0.01, 0.1V
Alternating Voltage (UI-N,UL-L,UL-E)	0~440V	±(3%+3V)	1V
Frequency	DC,45~65Hz	±1Hz	1Hz
Loop Resistance(RL)	0.1~2000Ω	±(10%+0.2d)	0.1Ω
RL Current Test	0.51 IΔN	±(10%+10d)	0.5IΔN
Multiplying Power of Measuring Current	x0.5,x1,x5
Current Level(IΔN)	10mA,30mA,100mA 300mA,500mA
Trigger Phase Angle	0°or 180°
FEATURE
Auto Power Off	√
Display Back Light	√
Data logging And recall	100groups
Low Battery indication	√
USB2.0 Interface	√
GENERAL
Power Supply	6x1.5V AA batteries(not included this order)
Product Size	180mm x 140mm x65mm
Product Weight	Approx. 950g
Safety Rating	CE ETL CAT.III 300V
