Home > Products > Electrical Instruments > High quality MS2203 3 phase TRMS Digital clamp Meter power factor correction multimeter
High quality MS2203 3 phase TRMS Digital clamp Meter power factor correction multimeter
- 50 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Graigar | Model Number: | MS2203 |
Display Type: | Digital Only | Measuring Current Range: | 0.1~1000A AC | Operating Temperature: | 0~40C |
Dimensions: | 300x103x51mm | Weight: | 640g |
Product Description
High quality MS2203 3 phase TRMS Digital clamp Meter power factor correction multimeter
Specifications
MS2203 Three Phase Power Factor Meter
1.Ture RMS
2.Data logger
3.Jaw 50mm
4.CE CAT .III 600V RoHS
Specifications | RANGE | ACCURACY | ||
AC Voltage | 0.1~600V | ±(1.2%+5) | ||
AC Current | 0.1A~1000A | ±(2.0%+5) | ||
Active Power | 0.1kW~600kW | ±(3.0%+5) | ||
Apparent power | 0.1kVA~600kVA | ±(3.0%+5) | ||
Reactive power | 0.1kVAr~600kVAr | ±(4.0%+5) | ||
Power Factor | 0.3~1 | ±(2.0%+2) | ||
Active Energy | 0.001kWh~10000kWh | ±(3.0%+2) | ||
Frequency | 20Hz~1000Hz | ±0.5% | ||
FEATURE | Auto Power Off | √ | ||
Auto Ranging | √ | |||
Max/min | √ | |||
Data Hold | √ | |||
Display Back Light | √ | |||
Jaw opening | Ø50mm/2.0” | |||
Data logging And recall | 28 groups | |||
LBD | Low Battery indication | |||
True RMS | True Root Mean Square Measurement | |||
Display | 9999 counts | |||
Rs232 Interface | √ | |||
GENERAL | ||||
Power Supply | 4 x 1.5V AA Batteries | |||
Product Size | 300mm x103mm x51mm(11.8" x4.1" x2.0") | |||
Product Weight | 640g(1.4lb) | |||
Category | CE CAT .III 600V RoHS | |||
