Handheld Automotive Multi-Purpose Meters UT106 Ac/dc Voltage Current Tester Multimeter
US$ 12 - 18
MOQ: 3 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT106
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Handheld Automotive Multi-Purpose Meters UT105 Ac/dc Voltage Current Tester MultimeterUS$ 10 - 16MOQ: 3 Pieces -
General Digital Multimeters UNI-T UT58C Ac/dc Voltage Current Tester 1000V 20AUS$ 15 - 25MOQ: 1 Piece
-
B35T OWON DM Series Digital Multimeter Function as 3 in 1,multi-connection Supported via Mobile App,larger DisplayUS$ 20 - 60MOQ: 1 Piece
-
Standard Digital Multimeters UNI-T UT55 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter MultitesterUS$ 18 - 23MOQ: 5 Pieces
-
Standard Digital Multimeters UNI-T UT54 DC/AC Voltmeter Ammeter Ohmmeter Tester LCD Backlight Multimetro Ammeter MultitesterUS$ 18 - 23MOQ: 5 Pieces
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT106
Measuring Current Range
200mA/10A
Measuring Voltage Range
200mV/2V/20V/200V/1000V
Measuring Resistance Range
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
Measuring Capacitance Range
100uF
Measuring Inductance Range
1000V/1000V
Operating Temperature
-40°C - 1000°C
Dimensions
179mm * 88mm * 39mm
Handheld Automotive Multi-Purpose Meters UT106 ac/dc Voltage Current Tester Multimeter
Introduction
UT105 Meter is a 1999 count digital multimeter manual range cars. It has a large screen, full-featured symbol display and input connections prompt, full scale overload protection and unique design, making it more secure and better performance of electrical instruments.
This instrument can be used to measure: AC and DC voltage, DC current, resistance, diodes, circuit continuity and the car speed and angle closure.
Specification
| Specifications | Range | Best Accuracy | ||
| Model | UT105 | UT106 | UT107 | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.5%+5) | ±(0.5%+2) | |
| 200mV/2V/20V/1000V | ±(0.5%+2) | |||
| AC Voltage (V) | 2V/20V/200V/750V | ± (0.8%+5) | ||
| 200V/750V | ± (0.8%+5) | ± (0.8%+5) | ||
| DC Current (A) | 200mA/10A | ± (0.8%+5) | ± (0.8%+5) | ± (0.8%+5) |
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ | ± (0.8%+5) | ± (0.8%+5) | |
| 200Ω/2kΩ/20kΩ/200kΩ/20MΩ | ± (0.8%+5) | |||
| Frequency (Hz) | 2kHz | ±(2%+5) | ±(2%+5) | |
| Temperature (°C) | -40°C - 1000°C | ±(2%+8) | ±(2%+8) | |
| Features | ||||
| Display Count | 2000 | 2000 | 2000 | |
| Manual Range | √ | √ | √ | |
| Battery Test | 12V | ±(3%+5) | ||
| Duty Cycle | 1%-90% | ±(4%+5) | ||
| Diode | √ | √ | √ | |
| Continuity Buzzer | √ | √ | √ | |
| Low Battery Indication | √ | √ | √ | |
| Data Hold | √ | √ | √ | |
| Input Protection | √ | √ | √ | |
| Input Impedance for DCV | Around 10MΩ | √ | √ | √ |
| Dwell | 4CYL/6CYL/8CYL | ±(3%+5) | ±(3%+5) | ±(3%+5) |
| Tach | 4CYL/6CYL/8CYL | ±(3%+5) | ±(3%+5) | ±(3%+5) |
| General Characteristic | ||||
| Power | 9V Battery(6F22) (not included) | |||
| LCD Size | 60mm * 54 mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 351g(Including Holster) | |||
| Product Size | 179mm * 88mm * 39mm | |||
| Standard Accessories | UT105-Battery, Test Lead, Holster | |||
| UT106/UT107-Battery, Test Lead, Holster, Point Contact Temperature Probe | ||||
| Standard Individual Packing | Gift Box, English Manual | |||
| Standard Quantity Per Carton | 40 PCs | |||
| Standard Carton Measurement | 645mm*450mm*340mm (0.0987 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 24.6 Kg |
|||
Accessory
1. Battery,(not included)
2. Test Lead,
3. Holster
4. Point Contact Temperature Probe
