Industrial True RMS Digital Multimeters UNI-T UT171A Datalogger 60nS Admittance Multipurpose Meter Tester
US$ 100 - 160
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
ut171a
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
OWON DCM Series Digital Clamp Meter CM240 Auto- / Manual Range FunctionUS$ 300 - 300MOQ: 1 Piece -
UNI-T UT522 Digital Earth Ground Resistance Tester Lightning Rod Lightning Detector Low TesterUS$ 80 - 110MOQ: 1 Piece
-
UNI-T UT151A Modern Digital Multimeter LCD Handheld Mini Multipurpose Meter ac dc Volt Amp Ohm Capacitance TesterUS$ 50 - 100MOQ: 1 Piece
-
Professional UT205A LCD Digital 1000 Clamp Multimeters DC AC Volt Ampere Ohm Hz Auto Range Tester MetersUS$ 20 - 30MOQ: 3 Pieces
-
UNI-T Automotive Digital Palm-Size Multimeter UT71C Intellgent Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto RangeUS$ 82 - 120MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
ut171a
Measuring Current Range
400uA--10A
Measuring Voltage Range
400mV-1000V
Measuring Resistance Range
400Ω--40MΩ
Measuring Capacitance Range
4nF-40mF
Measuring Inductance Range
none
Operating Temperature
-40℃~1000℃
Dimensions
206mm x 95mm x 55mm
Industrial True RMS Digital Multimeters UNI-T UT171A Datalogger 60nS Admittance Multipurpose meter tester
Introduction
UT171 series digital multimeter is with high accuracy, high reliability, high security, auto range of features.
Accurate measurement of the voltage signal at 100KHz conditions broadband, square wave signal, conductivity nS and other signals;
Product chip set VFC start mode, the internal will go through a particular filter circuit filters out high-frequency interference signal, ensuring accurate measurement data! It can be applied occasions with VFC frequency voltage, full scale overload protection and unique design, making performance more remarkable generation of practical electrical measuring instruments.
It can be used to detect various types of universities, smelting, telecommunications, manufacturing, oil, defense, electricity, electrical, circuits, electrical equipment, maintenance and repair of the ideal tool.
Specification
| Specifications | Range | Best Accuracy | ||
| Model | UT171A | UT171B | UT171C | |
| DC Voltage (V) | 400mV/4V/40V400V/1000V | ±(0.025%+5) | ||
| 600mV/6V/60V/600V/1000V | ±(0.025%+5) | ±(0.025%+5) | ||
| AC Voltage (V) | 400mV/4V/40V400V/750V | ±(0.4%+40) | ||
| 600mV/6V/60V/600V/750V | ±(0.4%+40) | ±(0.4%+40) | ||
| DC Current (A) | 400uA/4000uA/40mA/400mA/4A/10A | ±(0.15%+2) | ||
| 600uA/6000uA/60mA/600mA/6A/10A | ±(0.15%+2) | ±(0.15%+2) | ||
| AC Current (A) | 400uA/4000uA/40mA/400mA/4A/10A | ±(0.75%+5) | ||
| 600uA/6000uA/60mA/600mA/6A/10A | ±(0.75%+5) | ±(0.75%+5) | ||
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(0.05%+2) | ||
| 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ | ±(0.05%+2) | ±(0.05%+2) | ||
| Admittance (nS) | 60nS | ±(1.0%+10) | ±(1.0%+10) | |
| Capacitance(F) | 4nF/40nF/400nF/4μF/40μF/400μF/4mF/40mF | ±(2.5%+40) | ||
| 6nF/60nF/600nF/6μF/60μF/600μF/6mF/60mF | ±(2.5%+40) | ±(2.5%+40) | ||
| Frequence (Hz) | 10Hz~10MHz | ±(0.01%+5) | ±(0.01%+5) | ±(0.01%+5) |
| Temperature (℃) | -40℃~1000℃ | ±(1.0%+30) | ±(1.0%+30) | |
| Temperature (℉) | -40℉~1832℉ | ±(1.5%+50) | ±(1.5%+50) | |
| Features | ||||
| Display Count | 40000 | 60000 | 60000 | |
| Auto/Manual Range | √ | √ | √ | |
| True RMS | √ | √ | √ | |
| Bandwidth (Hz) | 100KHz | √ | √ | √ |
| AC + DC | √ | √ | ||
| V.F.C | √ | √ | ||
| 4~20mA Loop | 0~100% | √ | √ | |
| LoZ(ACV) | Around 3KΩ | √ | √ | |
| Diode | Around 3.0V | √ | √ | √ |
| Continuity Buzzer | √ | √ | √ | |
| Duty Cycle | 1%~99% | √ | √ | √ |
| Square Wave Output | √ | |||
| NCV | √ | √ | √ | |
| Data Hold/MAX/MIN | √ | √ | √ | |
| Relative Mode | √ | √ | √ | |
| Peak Hold | √ | √ | ||
| Data Storage | 999 | 9999 | 9999 | |
| Date Time Display | √ | |||
| Data Comparsion Function | √ | √ | ||
| USB Interface | √ | √ | √ | |
| Display Type | LCD | EBTN | OLED | |
| LCD Backlight | √ | √ | √ | |
| Analogue Bar Graph | √ | √ | √ | |
| Mis-plug Alarm | √ | √ | √ | |
| Low Battery Indication | √ | √ | √ | |
| Rechargeable Battery | √ | √ | ||
| Auto Power Off | Around 15 Minutes | √ | √ | √ |
| Input Protection | √ | √ | √ | |
| Input Impedance for DCV | Around 1GΩ | √ | √ | √ |
| General Characteristic | ||||
| Power | UT171A - AA 1.5V x , UT171B/C -7.4V 2000mAh Li-ion Battery | |||
| LCD Size | UT171A - 70.6mm x 49.5mm,UT171B/C - 70.6mm x 35.3 mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 384g | |||
| Product Size | 206mm x 95mm x 55mm | |||
| Standard Accessories | Batteries, Test lead, Point Contact Temperature Probe, USB Interface Cable, Power Adaptor(For UT171B/C),PC Software CD | |||
| Standard Individual Packing | Gift Box, Carrying Bag, English Manual | |||
| Standard Quantity Per Carton | 20 PCs | |||
| Standard Carton Measurement | 530mm × 360mm × 285mm (0.055 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 22 Kg | |||
| Optional Accessories* | Bluetooth Adaptor (UT-D07) | |||
Accessory
1. Batteries,
2. Test lead,
3. Point Contact Temperature Probe,
4. USB Interface Cable,
