UNI-T UT221 UT-221 Professional LCD Backlight 2000A True RMS Digital Clamp Meters Multitester W/ Frequency & Duty Cycle Test
Product profile:
An ideal tool for the maintenance and troubleshooting needed in metallurgy, manufacturing, petroleum, electric power, chemical industry, etc
Auto Range: √
Jaw Opening: 63mm
True RMS: AC Voltage/AC Current
Duty Cycle: 0.1%~99.9%
Diode: √
Continuity Buzzer: √
Low-Pass Filtering: √
Inrush Current: √
AC Current: √
Relative Function: √
Data Hold: √
MAX: √
MAX/MIN: √
LCD Backlight: √
Analogue Bar Analogue: 66
Full Icon Display: √
Auto Power Off: √
Low Battery Indication: √
Input Impedance: ≥10MΩ
Specifications:
Model: UT221
AC Current(A): 660A/2000A ±(2.5%+5)
DC Current(A): 660A/2000A ±(2.5%+5)
AC Voltage(V): 6.6V/66V/660V/750V ± (1.2%+5)
DC Voltage(V): 6.6V/66V/660V/750V ±(0.8%+1)
Resistance(Ω): 660Ω/6.6kΩ/66kΩ/660kΩ/6.6MΩ/66MΩ ±(1.0%+2)
Frequency(Hz): 66Hz/660Hz/6.6kHz/66kHz/660kHz/6.6MHz/20MHz ±(0.1%+3)
General Characteristic:
Power: 9V Alkaline Battery(6LF22) (not included)
LCD Size: 43mm * 30 mm
Product Color: Red and Grey
Product Net Weight: 725g
Product Size: 298mm * 100mm * 48mm
Package Size: 35.5 * 28.5 * 9.7cm /14 * 11.2 * 3.8in
Package Weight: 2312g /5.1lb
Package List:
1 * UNI-T UT221 Digital Clamp Meter
1 * Test Lead
1 * Output Cable
1 * Tool Box
1 * Manual
