Product Details
| Place of Origin: | Guangdong, China | Brand Name: | UNI-T | Model Number: | UT531 |
| Measuring Current Range: | 600mA | Measuring Voltage Range: | 1000V | Measuring Resistance Range: | 40MΩ |
| Measuring Capacitance Range: | 100uF | Operating Temperature: | -40°C -537°C | Dimensions: | 96.7mm X 202.8mm X46 mm |
Product Description
UNI-T UT531 LCD Insulation Digital Multimeter Volt Amp Ohm Capacitance Tester
Detailed
UT530 series insulation multimeter, full-featured digital multimeter and digital insulation tester as one of the true
RMS multimeter, powered by batteries, true RMS, store the data of 99 set, the accuracy is 0.09%, the biggest
show 6000.
Suitable for applications in precision tools (cable, motor, transformer) test.
Contrast
| Specifications | Range | Best Accuracy | |||
| Model | UT531 | UT532 | UT533 | ||
| Insulation Resistance(Ω) | Test Voltage | 500V/1000V | 0%-10% | ||
| 250V/500V/1000V | 0%-10% | ||||
| 50V/100V/500V/1000V/2500V | 0%-10% | ||||
| 50V | 0.1MΩ~50.0MΩ | ±(3%+5) | |||
| 100V | 0.1MΩ~100.0MΩ | ±(3%+5) | |||
| 250V | 0.2MΩ~99.9MΩ | ±(3%+5) | ±(3%+5) | ||
| 100MΩ~250MΩ | ±(3%+5) | ±(3%+5) | |||
| 500V | 0.5MΩ~99.9MΩ | ±(3%+5) | ±(3%+5) | ±(3%+5) | |
| 100MΩ~500MΩ | ±(3%+5) | ±(3%+5) | ±(3%+5) | ||
| 1000V | 4.0MΩ~99.9MΩ | ±(3%+5) | ±(3%+5) | ±(3%+5) | |
| 100MΩ~600MΩ | ±(3%+5) | ||||
| 100MΩ~999MΩ | ±(3%+5) | ±(3%+5) | |||
| 1.00GΩ~2.00GΩ | ±(5%+5) | ±(5%+5) | |||
| Short-Circuit Current | <2mA | √ | √ | √ | |
| Multimeter Specifications | |||||
| DC Voltage (V) | 60mV/600mV/6V/60V/600V/1000V | ±(0.09%+6) | ±(0.09%+6) | ±(0.09%+6) | |
| AC Voltage(50Hz~1KHz) | 6V/60V/600V/1000V | ±(1%+3) | ±(1%+3) | ±(1%+3) | |
| DC Current (A) | 60mA/600mA | ±(1.0%+2) | ±(1.0%+2) | ±(1.0%+2) | |
| AC Current(50Hz~1KHz) | 60mA/600mA | ±(1.5%+2) | ±(1.5%+2) | ±(1.5%+2) | |
| Resistance (Ω) | 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/40MΩ | ±(0.9%+2) | ±(0.9%+2) | ±(0.9%+2) | |
| Capacitance (F) | 10nF/100nF/1μF/10μF/100μF | ±(3%+5) | ±(3%+5) | ±(3%+5) | |
| Frequency (Hz) | 60Hz/600Hz/6KHz/60KHz/600KHz/1MHz | ±(0.1%+3) | ±(0.1%+3) | ±(0.1%+3) | |
| Temperature (°C) | -40°C -537°C | ±(1%+10) | ±(1%+10) | ||
| Temperature (°F) | -40°F-998°F | ±(1%+18) | ±(1%+18) | ||
| Features | |||||
| Display Count | 6000 | 6000 | 6000 | ||
| Auto Range | √ | √ | √ | ||
| True RMS | √ | √ | √ | ||
| Diode | √ | √ | √ | ||
| Auto Power Off | √ | √ | √ | ||
| Continuity Buzzer | √ | √ | √ | ||
| Low Battery Indication | √ | √ | √ | ||
| Data Hold | √ | √ | √ | ||
| MAX/MIN | √ | √ | √ | ||
| Data Logging | 99 | 99 | 99 | ||
| LCD Backlight | √ | √ | √ | ||
| Full Icon Display | √ | √ | √ | ||
| General Characteristic | |||||
| Power | 1.5V Alkaline Batteries(LR6)×6 | ||||
| LCD Size | 81mm X 46mm | ||||
| Product Color | Red and Grey | ||||
| Product Net Weight | 505g | ||||
| Product Size | 96.7mm X 202.8mm X46 mm | ||||
| Standard Accessories | UT531-Batterise, Test Lead, Alligator Clip, Carrying Bag | ||||
| UT532/533-Batterise, Test Lead, Alligator Clip, Point Contact Temperature Probe, Carrying Bag | |||||
| Standard Individual Packing | Gift Box,English Manual | ||||
| Standard Quantity Per Carton | 20 pcs | ||||
| Standard Carton Measurement | 460mm X 310mm X 368mm(0.053 CBM Per Standard Carton) | ||||
| Standard Carton Gross Weight | 12Kg | ||||
Fitting
1. Batterise,(not included)
2. Test Lead,
3. Alligator Clip,
4. Carrying Bag
