Handle pre-inserted bottles blowing machines
- 1000 Piece / Pieces per Month
- Guangzhou
- T/T Credit Card
- High speed Plastic bottle making 0.5L- 2L 6000BPH Automatic PET bottle blow blowing mold molding machine prices
- Factory Price High Quality Automatic Fast Plastic PP HDPE Bottle Blowiing Jerrycan Extrusion Blow Molding Machine
- Semi Automatic PET Plastic Bottle 5 Gallon 20 Liter Blow Molding Machine Price
- custom design semi-automatic preform pet plastic bottle blowing blow molding machine high speed
- Semi-automatic Two Cavity Bottle Making Machine Blow Molding Equipment
- Plastic bottle blowing machine Beverage bottle blowing machine Medicine bottle blowing machine
Product Details
Condition: | New | Application: | Bottle | Plastic Processed: | PET |
Blow Moulding Type: | Stretch Blow Moulding | Automatic: | Yes | Place of Origin: | Guangdong, China |
Brand Name: | Henggang | Model Number: | HGA.C-2C | Voltage: | 380v |
Power(W): | 16kw | Dimension(L*W*H): | 2520*1350*1750mm | Weight: | 1500kgs |
Certification: | CE | Warranty: | 1 YEAR | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Detailed Product Description of Handle pre-inserted bottles blowing machines:
This kind of machine could blow edibble oil bottle with handle and other kinds bottle with handle.
Preform material:PET
Output:1600BPH(2000ml)
Features of Handle pre-inserted bottles blowing machines:
1.Using hydro-pneumatic linkage mold clamping mechanism which runs stably with high speed and great clamping force.
2.The control system adopts man-machine interface with Mitsubishi PLC which is of high sensitivity and accuracy.
3.Using coated infrared heating lamps which enable fast and stable heating.
4.Using centralized noise-reducing air recycling system which minimize the noise as much as possible.
5.Using slide core in stepping unit which is easy to operate and saves energy.
Parameters of Handle pre-inserted bottles blowing machines:
Item | HGA.C-2C | |
Container | Max. Container Volume | 2000 ml |
Neck Diameter Range | 50 mm | |
Max. ContainerDiameter | 105 mm | |
Max. Container Height | 330 mm | |
Theoretical Output | 1600 bph | |
Molding | Clamping stroke | 150 mm |
Stretching stroke | 450 mm | |
Bottom Stoke | 25 mm | |
Preform distance | 130 mm | |
Preform Holder | 89 pcs | |
Cavities | 2 No. | |
Electrical System | Max. Heating Power | 32 kw |
Heating Power | 7 kw | |
Air System | Operating Pressure | 7 kg/c m2 |
Low Air Consumption | 1000 ltr/min | |
Blowing Pressure | 35 kg/c m2 | |
High Air consumption | 1600 ltr/min | |
Cooling Water | Operating Pressure | 5-6 kg/c m2 |
Temperature | 8-12°C | |
Flow rate | 30 ltr/min | |
Machine | Size(L×W×H) | 2520×1350×1750mm |
Weight | 1500 kg |
The picture of Handle pre-inserted bottles blowing machines:
Product picture:
Compressor High pressure
Compressor Low pressure
All the cavity molds(moulds) are manufactured by ourselves. We have our own CNC processing machine and experienced engineer, who has been making cavity molds at least 5 years. Besides the cavity molds, other hardware parts are also produced by ourselves. Thus we have strong confidence in the stability of our machine because all parts can jointed and worked as a integrated unit.
The most frequently used material for molds are Aluminum, S136(stainless iron):
Our engineer is making the technical drawing by the software UG:
Our engineer is checking the process of the cavity moulds in the CNC machine:
Our master is drilling the holes for the installation of the molds, the drilling is strictly made according to the technical drawing, thus the combination of the parts will be matched perfectly.
Our Handle pre-inserted bottles blowing machines has already accquired the CE certificate:
Other domestic patents of our auto Handle pre-inserted bottles blowing machines:
