Detailed Product Description of Handle pre-inserted bottle blow molding machine:
This kind of machine could blow edibble oil bottle with handle and other kinds bottle with handle.
Preform material:PET
Output:1600BPH(2000ml)
Features of Handle pre-inserted bottle blow molding machine:
1.Using hydro-pneumatic linkage mold clamping mechanism which runs stably with high speed and great clamping force.
2.The control system adopts man-machine interface with Mitsubishi PLC which is of high sensitivity and accuracy.
3.Using coated infrared heating lamps which enable fast and stable heating.
4.Using centralized noise-reducing air recycling system which minimize the noise as much as possible.
5.Using slide core in stepping unit which is easy to operate and saves energy.
Parameters of Handle pre-inserted bottle blow molding machine:
Item |
HGA.C-2C |
|
Container |
Max. Container Volume |
2000 ml |
Neck Diameter Range |
50 mm |
|
Max. ContainerDiameter |
105 mm |
|
Max. Container Height |
330 mm |
|
Theoretical Output |
1600 bph |
|
Molding |
Clamping stroke |
150 mm |
Stretching stroke |
450 mm |
|
Bottom Stoke |
25 mm |
|
Preform distance |
130 mm |
|
Preform Holder |
89 pcs |
|
Cavities |
2 No. |
|
|
Electrical System |
Max. Heating Power |
32 kw |
Heating Power |
7 kw |
|
Air System |
Operating Pressure |
7 kg/c m2 |
Low Air Consumption |
1000 ltr/min |
|
Blowing Pressure |
35 kg/c m2 |
|
High Air consumption |
1600 ltr/min |
|
Cooling Water |
Operating Pressure |
5-6 kg/c m2 |
Temperature |
8-12°C |
|
Flow rate |
30 ltr/min |
|
Machine |
Size(L×W×H) |
2520×1350×1750mm |
Weight |
1500 kg |
|
The picture of Handle pre-inserted bottle blow molding machine:
Product made by Handle pre-inserted bottle blow molding machine:
Compressor High pressure
Compressor Low pressure
All the cavity molds(moulds) of Handle pre-inserted bottle blow molding machine are manufactured by ourselves. We have our own CNC processing machine and experienced engineer, who has been making cavity molds at least 5 years. Besides the cavity molds, other hardware parts are also produced by ourselves. Thus we have strong confidence in the stability of our machine because all parts can jointed and worked as a integrated unit.
The most frequently used material for molds are Aluminum, S136(stainless iron):
Our engineer is making the technical drawing by the software UG:
Our Handle pre-inserted bottle blow molding machine has already accquired the CE certificate:
