Wireless Outdoor 300Mbps 5.8G CPE/ Network Bridge/Access Point
Key Feature
1. 2T2R,5.8GHz only
2. Data Rate up to 300Mbps
3. Multiple SSID up to 4
4. Support PTP and PTMP(Point to Multi-point)
5. Multi-operation mode :AP/Gateway/ WISP(CR)/WDS /Client Bridge
6. WPA2/WPA/AES/TKIP,SSH and 802.1x Authenticator
7. MAC & IP Address and URL Filter
8. Supports UPnP, Dynamic DNS, Static Routing
9. Supports PPPoE, Dynamic IP, Static IP Internet Access
10. 2x LAN(10/100Mbps)FE
11. IP65 outdoor Weather-proof housing
12. 14dBi dual-polarized antenna to build long distance Wi-Fi connection
13. Passive POE based 2 LAN port (24V input) for flexible deployment
14. Emergency Recovery Push button Provide a self-aid page for users in case of firmware upgrade failure
Description
XL-AR44B 5.8G High Power Wireless outdoor WISP AP/CB is dedicated to long distance wireless network solutions, which is a revolutionary design with its features of conciseness, quality, and flexibility. It features 14dBi internal Dual-Polarized Antenna,high output power and high RX sensitivity can significantly extend the transmission range up to 2km-3km to deliver a more stable wireless connection and reduce the expense of equipment.
Specifications
Specification | ||||
Hardware | ||||
MCU |
AR9344 |
|||
RF |
2T2R |
|||
Memory |
64MB RAM |
|||
Flash |
4MB(May extend to 8MB) |
|||
Interface |
2 x RJ-45 for 10/100 Mbps |
|||
1 x Reset button(reset & factory defaults) | ||||
| ||||
Power |
24V/1A Passive POE |
|||
RF | ||||
Frequency |
802.11b/g/n |
|||
5.180-5.240GHz | ||||
5.745-5.825GHz | ||||
Modulation |
OFDM = BPSK,QPSK, 16-QAM, 64-QAM |
|||
DSSS = DBPSK, DQPSK, CCK | ||||
Throughput |
300 Mbps |
|||
Sensitivity |
802.11n |
802.11g |
802.11b |
|
-86dBm @ MCS0 |
- 90dBm @ 6Mbps |
- 92dBm @ 1Mbps |
||
-68dBm @ MCS7 |
- 72dBm @ 54Mbps |
- 85dBm @ 11Mbps |
||
Output Power |
Radio1(WLAN1) |
|||
802.11n(5.8GHz)(± 1.5dBm) 25dBm |
802.11g(± 1.5dBm) 27dBm |
|
||
25dBm @ MCS0~2/MCS8~10 |
27dBm @ 6~24Mbps |
|
||
Antenna |
Internal 14dBi directional ANT |
|||
Software | |
Operation Mode |
Access Point / Ap Client /Gateway / WISP |
Protocol/Standard |
IEEE 802.3(Ethernet) |
IEEE 802.3u(Fast Ethernet) | |
IEEE 802.11b/g/n(5.8G WLAN) | |
Wireless |
Auto-channel selection |
Multiple SSID (4 SSID) | |
WDS AP / WDS Bridge | |
BSSID | |
Security |
WEP Encryption-64/128/152 bit |
WPA/WPA2 Personal (WPA-PSK using TKIP or AES) | |
WPA/WPA2 Enterprise (WPA-EAP using TKIP) | |
Hide SSID | |
MAC/IP address &URL filtering | |
Wireless STA (Client) connected list | |
Management | |
System Settings |
Web-based configuration(HTTP/Telnet) |
Firmware Upgrade |
Upgrade firmware via web browser or TFTP |
Administration |
Admin Password can be configured |
System monitoring |
Status in hand , useful statistic and Event log |
Logs |
Supports local logs,logs host,logs file export |
Reset |
Renew system or restore to factory defaults |
Backup |
Restore settings & configuration of the device to local file |
Physical Property | |
Temperature |
Working: -10°C~55°C |
Storage: -20°C to 70°C | |
Humidity |
5%~95%( typical) |
Waterproof |
IP65 |
