Help CenterAPC 5M-12
Related Products
Type Integrated directional dual-polarized panel
Gain 12 dBi
Interface 10/100 Base-T, RJ45
Built-in surge protection Yes
Operating modes Bridge, Router
WAN Static IP, DHCP client, PPPoE client
NAT Routing w/ or w/o NAT
Static routing Supported
DHCP Client, Server, Relay
Port forwarding Supported
VLAN Supported for management and data
General Ability to define/limit frequency, channel width, EIRP, modulation
Advanced wireless functionality ATPC (automatic transmit power control), DFS3,auto-channel,auto- modulation
Operating mode Router, Bridge
Wireless operating modes AP, Station, AP WDS, Station WDS, Virtual radios (VSSID), iPoll access point, iPoll client
Wireless security WPA/WPA2 Personal, WPA/WPA2 Enterprise, WACL, User isolation, UAM (web
portal authentication)
Wireless QoS WMM
WAN protocols Static IP, DHCP client, PPPoE client
Network NAT, static routing, firewall, port forwarding, VLAN, traffic shaping
Services DHCP server, SNMP server, NTP client, Alerts, Remote syslog, Wireless and Ethernet statistics, bandwidth limiting
Management HTTP(S) GUI, SSH CLI, SNMP read, WNMS, troubleshooting file, reset via reset
tool
Tools Site survey, Link test, Antenna alignment, Ping, Traceroute, Spectrum analyzer,
delayed reboot
Dimensions Length 150mm (5.9"), width 115mm (4.5"), high 55 mm (2.1")
Weight 400 g (16.2 oz)
Power supply 12 - 24 V DC passive PoE
Power source 100 – 240 VAC via included adapter
Power consumption 6.5 W
Operating temperature -20°C (-4F) ~ +60°C (+140F)
Humidity 0 ~ 90 % (non-condensing)
System configuration User-friendly web GUI, Command line via SSH, centralized Wireless Network Management System, reset via reset tool
System monitoring SNMP v1/2c/3 server, Syslogs, system alerts via e-mail and SNMP trap
Certification FCC/CE
Safety RoHS compliant
