Dynamic Fan Balance Instrument

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Model Number:

YFW

Power:

Electronic

Taian Tongchuang Balancing Machine LLC.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Brand Name TC

Model Number YFW

Power Electronic

Usage Balancing Machine

Specifications

balance instrument
dynamic fan balance
CE certified
Windows XP operation system
competitive price

Universal Fan Balancing Machine

Hard backing;
Specified for fan and blower balancing;
High initial unbalance permitted;
High precision;
Reasonable price

Features:

Hard backing horizontal dynamic balancing machine;

Using the wheel backing, universal joint to drive;

Industrial control computer data processing, color screen real-time shows the amount and angle of unbalance ,rotation speed;

Bed is overall foundry with good stability

Balance and measure on single side, double side

Technical Data:

Model	Weight of workpiece (kg)	Max.diameter of workpiece(mm)	Distance between two support bearings(mm)	Range of .rotor Diameter(mm)	Balancing speed (r/min)	Min.achievable residual unbalance (g.mm/kg):	Unbalance reduction ratio(%):	Drive power (kw)
YFW-300	10-300	Φ1650	1700	Φ10-180	300-2500	≤0.5	≥90	5.5
YFW-1000	20-1000	Φ1800	1600	Φ20-240	300-2500	≤0.5	≥90	7.5
YFW-1600	30-1600	Φ2000	1600	Φ20-240	300-2500	≤0.5	≥90	11
