Help CenterBelt Drive Balancing Machine, Grinding Machine Balancer
Related Products
-
Belt Drive Balancing Machine, Crusher Balancing MachineNegotiableMOQ: 1 Set -
Balancing Machine, Harvesting Machine BalanceNegotiableMOQ: 1 Set
-
Balance Machine, Rotator Balancing MachineNegotiableMOQ: 1 Set
-
Horizontal Crushing Machine Balancer(YYQ Series)NegotiableMOQ: 1 Set
-
Dynamic Balancing Machine, Brake Disc BalancerNegotiableMOQ: 1 Set
Specifications
balance machinebalancer
Hard bearing
Belt drive
17 inch screen displays unbalance value, phase, rt rotate speed
Warranty period:
Life-time warranty. Any problem caused by our party within one year from the date of shipment, we will provide free spare parts for the repairment. After one year, we can provide the spare parts, but the user should pay for the related cost, including cost of the spare parts, delivery cost etc.
Technical Data:
Model |
Mass of workpiece (kg) |
Max.diameter of workpiece (mm) |
Distance between two support bearings(mm) |
Max.rotor Diameter (mm) |
Balancing speed (rpm) |
Min. achievable residual un balance(g.mm/kg): |
Unbalance reduction ratio(%): |
Drive power (kw) |
YYQ-5 |
0.1-5 |
400 |
50-600 |
3-40 |
400-5000 |
<=0.5 |
>=90 |
0.09 |
YYQ-16 |
0.3-16 |
500 |
60-600 |
5-40 |
400-5000 |
<=0.5 |
>=90 |
0.18 |
YYQ-50A |
1-50 |
900 |
60-800 |
8-70 |
300-5000 |
<=0.5 |
>=90 |
0.75 |
YYQ-100A |
2-100 |
900 |
80-1000 |
10-140 |
300-5000 |
<=0.5 |
>=90 |
1.5 |
YYQ-160A |
2-160 |
950 |
100-1400 |
10-180 |
300-2500 |
<=0.5 |
>=90 |
1.5 |
YYQ-300A |
5-300 |
1200
|
150-1500 |
20-180
|
300-2500 |
<=0.5 |
>=90 |
4.0 |
YYQ-500A |
10-500 |
1500
|
150-1500 |
20-240
|
180-2500 |
<=0.5 |
>=90 |
4.0 |
YYQ-1000A |
10-1000 |
1500
|
150-2600 |
20-240 |
180-2500 |
<=0.5 |
>=90 |
5.5 |
YYQ-1600A |
30-1600 |
1800 |
150-2600 |
20-240 |
180-2500 |
<=0.5 |
>=90 |
7.5 |
YYQ-3000A |
100-3000 |
2000
|
150-2600 |
15-300
|
180-2500 |
<=0.5 |
>=90 |
11 |
