Specifications
balance machinegrinding machine balance
horizontal hard bearing balancing machine
computer display
hard bearing, belt drive
Warranty period:
Life-time warranty. Any problem caused by our party within one year from the date of shipment, we will provide free spare parts for the repairment. After one year, we can provide the spare parts, but the user should pay for the related cost, including cost of the spare parts, delivery cost etc.
Technical Data:
Model |
Mass of workpiece (kg) |
Max.diameter of workpiece (mm) |
Distance between two support bearings(mm) |
Range of Journal Diameter (mm) |
Balancing speed (rpm) |
Min. achievable residual unbalance(g.mm/kg): |
Unbalance reduction ratio(%): |
Drive power (kw) |
YYQ-5 |
0.1-5 |
400 |
50-600 |
3-40 |
400-5000 |
<=0.5 |
>=90 |
0.09 |
YYQ-16 |
0.3-16 |
500 |
60-600 |
5-40 |
400-5000 |
<=0.5 |
>=90 |
0.18 |
YYQ-50A |
1-50 |
900 |
60-800 |
8-70 |
300-5000 |
<=0.5 |
>=90 |
0.75 |
YYQ-100A |
2-100 |
900 |
80-1000 |
10-140 |
300-5000 |
<=0.5 |
>=90 |
1.5 |
YYQ-160A |
2-160 |
950 |
100-1400 |
10-180 |
300-2500 |
<=0.5 |
>=90 |
1.5 |
YYQ-300A |
5-300 |
1200
|
150-1500 |
20-180
|
300-2500 |
<=0.5 |
>=90 |
4.0 |
YYQ-500A |
10-500 |
1500
|
150-1500 |
20-240
|
180-2500 |
<=0.5 |
>=90 |
4.0 |
YYQ-1000A |
10-1000 |
1500
|
150-2600 |
20-240 |
180-2500 |
<=0.5 |
>=90 |
5.5 |
YYQ-1600A |
30-1600 |
1800 |
150-2600 |
20-240 |
180-2500 |
<=0.5 |
>=90 |
7.5 |
YYQ-3000A |
100-3000 |
2000
|
150-2600 |
15-300
|
180-2500 |
<=0.5 |
>=90 |
11 |
