Product Description
PT124B-283 Silicon Flush Membrane Pressure transmitter , it designed with flameproof structure, pass EXibIICT4, according with standard of GB3836.1-2000 and GB3836.4-2000. And it comes with flush diaphragm, solves the problems during the measurement that the pressure port is easily blocked. The protection class of the transmitter house is IP65, it is suitable for outdoor installation, LCD display optional, make it easy to read value directly.With its high performance, this series product can interchange some high-grade pressure transmitters, for high precision measurement and control.
Product Parameter
Pressure range: 0-0.1MPa~0-200MPa
Over load: 150%FS
Burst pressure: 300%FS
Output: 4-20mA
Power supply: 12~36VDC
Response time: <5ms
Combine error: 0.5% FSO (Including Linearity, Repeatability & Hysteresis)
Pressure connection: M20×1.5,G1/2,1/2NPT(customer tailor)
Operating temperature: -20℃~80℃
Temperature compensation: 0℃~60℃
Electrical connector: Terminal Block
Explosion proof grade: ExibllCT4
Dimension
Factory Show
Product Application
Our products are widely used in the field of hydraulic pressure, air pressure, petrochemical industry, automotive, air condition and compressor, construction machinery, plastic extrusion, chemical fiber, plastic rubber machine, non-woven fabrics and etc.
Technical Team
ZHYQ has a strong R&D team with more than 10 staffs, there are 3 senior engineers, 5 intermediate engineers, in the major of mechatronics. They have successfully developed a lot of new and High-tech products, won a number of patents and awards.
