Description
PT124B-214 is corrugated Diaphragm 4-20mA pressure transmitter for high density liquid , it is with corrugated flush diaphragm is particularly suitable for the measurement of viscous fluids or media containing particulates that may clog the pressure connection of standard industrial transmitters. All wetted parts are made of stainless steel and are hermetically welded. it filled with environmental, avirulent medium slicon oil. If the pressure transmitter diaphragm damaged during process, the leaking medium is no harm to the human body or ambient . all our flush diaphragm pressure transmitter are international standard , it can replace the other brand like WKA , MEAS , KELLER ,HUBA etc , and the output can connect with the PLC directly .
Feature
It's desiged with corrugated diaphragm
This type can avoid clog the pressure connection
All wetted parts are made of stainless steel and are hermetically welded
This series is particularly suitable for the measurement of viscous fluids or particulates
High accuracy , diffused silicon elements
Application
Hydraulic Pressure
Polyurethane device
Medical pharmacy
Paper & Pulp, Paint
Food & Beverage Processing
Specification
Name |
corrugated Diaphragm 4-20mA pressure transmitter for high density liquid |
Model |
PT124B-214 |
Pressure range |
-1~0bar~16bar |
Over load |
150%FS |
Burst pressure |
300%FS |
Output |
4-20mA, 1-5V/0-5V, 0-10V |
Power supply |
12~36VDC |
Response time |
<5ms |
Combine error |
0.5% FSO (Including Linearity, Repeatability & Hysteresis) |
Repeatability |
≤ +/- 0.2%FSO |
Long term stability |
≤ +/-0.2%FS/year |
Pressure connection |
M20×1.5,G1/2,G1/4,1/2NPT ( customer tailor ) |
Operating temperature |
-20 °C ~ 80 °C |
Temperature compensation |
0°C ~ 60°C |
Electrical connector |
Bendix connector,Hirschman DIN4365 and Gland lead |
Dimension
Order Guide : with "* "are required , with "---"is optional
Model |
Range (bar) |
Output |
Screw Thread |
Electric connection |
Other requirement |
PT124B-214 |
* |
* |
* |
* |
--- |
Example:PT124B-214-10Bar-4-20mA-G1/2- DIN | |||||
Our company
Shanghai Zhaohui Pressure Apparatus Co., Ltd (ZHYQ) is the leading manufacturer which specializes in the design and construction of various transducer, transmitter and automation control products in China.
Founded in 1999, ZHYQ has actively brought in advanced production equipment and manufacturing process at home and abroad, developed and produced the transducers more than 80 series and 500 models successfully, which include industrial pressure transducer/transmitter, project equipment pressure transmitter, melt pressure transducer/ transmitter, melt pressure gauge, level transmitter, temperature transducer, tension transducer/ transmitter, burst Plug, intelligent digital indicator, and all kinds of sensor chips and etc.
ZHYQ insists on the development strategy with High-tech, High Quality, High level service, Creating world name brand, focuses on the challenge and stress attended by the customers, offers the competitive products and service and creates the economic value for the customers persistently.
Our factory
1. How do you ensure good product quality?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments before ship to our clients.
2. How fast can you delivery goods?
always 7-10 working days since order confirmed , if need goods urgently, we can arrange expedited production.
3. What’s your MOQ?
We have no MOQ limits, 1 piece for test purpose at first is acceptable.
4. How long is your product warranty?
7 days replacement and 12 months repair free of charge for quality problem
5. can you accept OEM brand ?
Yes, we can accept the OEM brand without extra charge .
6. Can you offer free samples?
Yes, we can offer free samples, however you should pay for the samples at first, and then we will return the cost when you release bulk order.
7. How long your quotation valid ?
our quotation valid for 6 months .
8. What trade terms , payment mode and payment terms can you accept?
Trade terms : Ex- Works, FOB, CNF
Payment mode: T/T, Western Union, PayPal, Money Gram
Payment terms: 100% payment before shipment
9. What express ways you can offer, can we use our own courier?
We can send goods to you by DHL, TNT, UPS, SF, EMS for freight prepard , also can use your own courier account to do the freight collect , just for your convenience.
