Help CenterYR--320 5 Colors 5UV Flexo Printer
Related Products
-
YR--4 Colors 1000\650\480\320 mm Flexographic Stacking Printing MachineryUS$ 15,000 - 32,000MOQ: 1 Set -
YR--5 Colors Stacking Type Flexo Printing MachineUS$ 15,000 - 32,000MOQ: 1 Set
-
Flexo Printig MachineUS$ 30,000 - 50,000MOQ: 1 Set
-
Plastic Cup Printing MachineUS$ 30,000 - 60,000MOQ: 1 Set
-
5 Color Lable Flexo Printing MachineUS$ 15,000 - 100,000MOQ: 1 Set
Specifications
Printing machine1.It's used for printing labels
2.Ceramic Anilox roller
3.with CE certificate
4.High printing precision.
Performance characteristics:
1, Adopt the ceramic anilox cylinder to transfer the ink.
2, Unwinding and rewinding are controlled by magnetic power brake, clutch, (Or controlled by auto tension controller of Mitsubishi of Japan).
3, Each printing unit adopts 3600 plate-adjustment.
4, IR dryer for each printing unit.(UV dryer is for option)
5, This machine has die-cutting station, and it can make printing and die cutting finished in one process.
6, The ink rollers will be separated from the printing roller, and keep running when the machine stopped.
7, The main motor adopts frequency conversion stepless timing motor.
8, The machine can finish material-feeding, printing, lighting, drying, laminating, die-cutting and rewinding in a lump.It is an ideal machine for printing note and top-grade adhesive label.
Main structure:
1.One Paste plate machine
2.One anilox roller for each group (LPI is optional, made in shanghai)
3.2 sets printing rollers
4.Printing both sides at the same time (with Reverse frame)
5.With the lamination station
6.One unwinding tension controller (Mitsubishi Japan)
7.One rewinding tension controller
8.magnetic power brake (made in wenzhou )
9.Frequency changer (Panasonic)
10.Mainframe: 2.2KW
Suitable material
Roll material such as paper, plastic, film, etc.
Printing colors
2-6 (colors )
Printing width
320mm
Printing length
142-320mm
Machine speed
70m/min
Printing speed
15-60m/min
Overprint precision
±0.1mm
Unwinding diameter
φ600mm
Rewinding diameter
φ500mm
Unwinding diameter of lamination
φ210mm
