Hot Sale PP Spun Filter Cartridge Making Machine From Reliable Manufacturer WUXI ANGE

Roots Blower

Air compressor and air tank

Could install variable frequency system

Could install variable frequency system

Itself could pre-heat the air to be 80~90 degree and to some extent it saves heating energy

Can NOT pre-heat the air

Maintenance fee is cheaper

Maintenance fee is costly

Air Displacement 6.32m³ /min;

Air Pressure: 0.8kgf/cm²

Thus, roots blower uses wind power to blow the liquid pp into pp fiber/silk and by control this to change the diameter of pp fiber;

Another difference, we think using roots blower is more saving heating electricity fee, because the air from roots blower has already been 80~90℃before it enters into the air heater(normally it needs to arrive 230℃ and keep). That’s why it saves power in air heating.

Air Displacement 5.0m³ /min;

Air Pressure: 0.8Mpa ≈

8.15kgf/cm²(1Mpa=1000000Pa)

Thus, and air compressor uses air pressure to blow the liquid pp into pp fiber/silk and by control this to change the diameter of pp fiber; Some customers think it is easier to control the air pressure of air compressor to change the diameter of pp fiber which is an important factor to affect pp filter micro. While in our experience both machines can make filter micro from 0.05micro to 100micro.

But if you choose our air compressor type, our air heater for air compressor could arrive 230℃in only 10minutes and then temperature never change and very stable.

Name

PP melt blown filter cartridge making machine/

PP spun filter making machine

Mode

UAC-2

Total Installed Power

64 KW

Actual Running Power

35-45 KW

Output

3500~4800pcs/day (refer to 10” filters)

Raw Material

100% New Polypropylene

Internal Diameter

28mm default (free to customize)

Outer Diameter

38~120mm (free to customize)

Length

5",10",20",30",...(free to customize)

Filter Precision

0-20 micron

Filter Surface

Smooth Surface (extra tool)

Orange Peel Surface (extra tool)

Micro-grooving Surface(extra tool)

Groove Surface (grooving machine)

Dotted Surface (extra tool)

Logo on Surface (carving machine)

Default Voltage

3 Phase 380V or;

1 Phase 220V

If you need other voltage, extra $500 shall be charged.

Machine Weight

2.6-3.5T

Operation Area

50m2(L*W)*3m (H) or above

Container Size

8~10 wooden boxes and use 20’’ container
