madrix led lighting control
Feature
1. 256 Gray,Gamma correction processing software.
2. Support the rules and special-shaped handle.
3. Controller, a port output, may bring 1024/2048 light.
4. Off-line control, play back content stored in the SD card
5. T-1000C store a maximum of 16 documents
Note
1 .The model T-1000S with one port output, When it control 512 pixels the speed can reach 30fps, more than 512 pixels, the frame speed will be slow down automatically
2 .When T-1000S controller control less than 512 lamps the frame rate can reach 30fps. When T-1000S control more than 512 lamps and less than 2048 lamps the frame rate will slow down automatically.
3 .T-1000S must use the new software LedEdit 2013.
Data
Chip type |
Software code& Controller type |
Lamps/(MAX) |
Note |
LPD6803,D705,1101,6909, 6912 |
T-1000-6803 |
2048 pixels |
|
LPD8806,LPD8809 |
T-1000-8806 |
2048 pixels |
|
TM1803,TM1804,TM1809,TM1812 |
T-1000-TM |
2048 pixels |
TM1804 and TM1809 are divided into high and low |
TM1903,TM1904,TM1909,TM1912 |
T-1000-TM19 |
2048 pixels |
|
UCS6909,UCS6912,UCS7009,UCS5903 |
T-1000-UCS-32 |
2048 pixels |
|
UCS1903,UCS1909,UCS1912 |
T-1000-UCS-256 |
2048 pixels |
1903 and 1909 are divided into high and low |
UCS3903 |
T-1000-UCS-1024 |
2048 pixels |
|
DMX512 |
T-1000-DMX |
170/512 pixels |
Compatible with standard DMX512 |
WS2801,WS2803 |
T-1000-WS |
2048 pixels |
|
WS2811 |
T-1000-WS2811 |
2048 pixels |
WS2811 be divided into high and low |
DS189 |
T-1000-DS189 |
2048 pixels |
|
TLS3001,TLS3002,TLS3008 |
T-1000-TLS |
* pixels |
|
P9813 |
T-1000-P9813 |
2048 pixels |
|
SM16715 |
T-1000-SM16715 |
2048 pixels |
SM16715 be divided into high and low |
SM16716 |
T-1000-SM16716 |
2048 pixels |
|
BS0901,BS0902 |
T-1000-0901 |
2048 pixels |
|
BS0815 |
T-1000-0815 |
2048 pixels |
|
T-1000S controller can control the following pixel ligt:
12mm round WS2801 led pixel light/led string
12mm flat led string light for festival
26mm Clear or milky cover led dot light
30mm led point light source with 4 pin JST connector
ws2811 Led strip-30led/m white PCB addressable strip
ws2811 Led strip-60led/m black PCB strip waterproof
WS2801 4 PCS 5050 Chips 3535 led pixel module
WS2801 3 Chips RGB led module
