4 Color Napkin Paper Flexo Printing Machine (CE)
1.The main features
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8 With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Print produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll
2.Main Technical Parameter
Model Item |
CH804-250 |
CH804-330 |
CH804-400 |
Material |
13g/m2-30g/m2 |
||
Material width |
250mm |
330mm |
400mm |
Printing color |
4 color/ Color |
||
Material specifications |
250×250mm |
250×250mm 330×330mm |
250×250mm 330×330mm 400×400mm |
Register precision |
Longitude:±0.20mm Transverse:±0.20mm |
||
Printing length |
200-500mm |
200-760mm |
200-900mm |
Anilox cylinder |
80DK-120DK (Germany made Titanium roller) / (Ceramic Cylinder) 200LPI-500LPI |
||
Printing plate lifting system |
Pneumatic press control |
||
Mechanical speed |
80m/min |
||
Printing speed |
60m/min |
||
Output (sheet/hr) |
14400 |
14400 10000 |
14400 10000 9000 |
Rewinder/Unwinder DIA |
ø 1000mm/ø 1200mm |
||
Master electric machinery |
3.7KW |
5.5 KW |
5.5KW |
Grind knife Motor |
0.75 KW |
1.1KW |
1.1 KW |
Dryer |
0.75 KW |
1.1 KW |
1.1 KW |
Unwind Motor |
1.1 KW |
1.5KW |
2.2KW |
Tension sensor |
2-10 Kg |
2-15 Kg |
2-20 Kg |
Aridity Mode |
6KW |
8KW |
11KW |
Master power |
12KW |
17KW |
20KW |
Weight |
3000Kg |
3200Kg |
3500 Kg |
Dimension (L×W×H) |
5.2m ×1.55m ×2.2m |
5.3m ×1.60m ×2.2m |
5.4m ×1.70m ×2.2m |
|
if have other require of machine, also can tell Ms Linda Wu freely!
| |||
3. Different Printing unit of our printing machine:
4. Safety package when delivery:
5. Our Workshop:
6. Photo on Chinaplas Fair:
7. CE Certificate:
FAQ:
1.Q: Are you a factory or trading company ?
A:We are a factory
2. Q: Where is your factory located ?How can I visit there ?
A:Our factory is located in Ruian City , Zhejiang Province ,China
about 40 minutes by plane from shanghai (5 hours by train )
3. Q: How is your after-sales service ?
A:We have been in this printing machine line of business for more than many years ,
we will send our professional engineer to install and test machine .So our after-sales service is always reliable.
4. Q:How can I get sample bags ?
A: We are honored to offer sample bags
5. Q:If your machines can print ..........
A : Our machines is multifunction , do roll to roll printing , such as paper, plastic film , woven bag , nonwoven .
Surely , you can offer your products, Let us confirm it . we will suggest you the best project.
6 .Q:How does your factory do regarding the quality control ?
A: We are the technical factory, we put more time on the quality control.
8. About Us:
