The main features
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8 With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Print produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll
Main Technical Parameter
Machine Colors |
2/ 4 /6 Colors |
|||||
Max. printing material width |
650mm |
850mm |
1050mm |
1250mm |
1450mm |
1650mm |
Max. printing width |
560mm |
760mm |
960mm |
1160mm |
1360mm |
1560mm |
Printing material |
OPP:20~70μm, BOPP:18~60μm, PE:35~100μm, NY:20~50μm, CPP:20~60μm, HDPE:20-80um, LDPE;20-80um, LLDPE: 20-80um. Paper: 20~100g/m2; Non woven material; |
|||||
Printing length(repeat) |
7.5"~40"(190mm~1000mm)/7.5"~50"(190mm~1270mm) |
|||||
Max. Mechanical speed |
90m/min |
|||||
Max. Printing speed |
10-70m/min (standard), (10-120m/min high speed as optional) |
|||||
Register precision |
Longitude:±0.25mm; Transverse:±0.25mm |
|||||
Press power |
Mechanic control |
|||||
Rewind/Unwind DIA |
Φ800mm |
|||||
EPC system: |
Edge Position Controller for unwind 1 Pcs |
|||||
Tension system |
Automatic tension control 2PCS |
|||||
Printing plate lifting system |
Automatic Hydraulic cylinder control printing roll up and down |
|||||
Anilox roll amd Inking way |
metal anilxo roll (300PLI) or ceramic anilox roller (100-800lpi) |
|||||
Drying model |
Electric heating |
|||||
Machine power |
28kw |
30kw |
32kw |
34kw |
36kw |
38kw |
Outline size |
5.4m × 2.0m × 3.2m |
5.4 m × 2.2m × 3.2 m |
5.4 m × 2.4m × 3.2 m |
5.4 m × 2.6m × 3.2 m |
5.4 m × 2.8m × 3.2 m |
5.4 m × 3.0m × 3.2 m |
1.Unwinding unit:
2.Printing unit:
3.Rewinding Unit:
1 Year Guarantee !
100% Good Quality !
24 Hours online Service!
