10dBi 800-2500MHZ RF directional coupler
- 500 Piece / Pieces per Month
- Guangzhou
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | G-Antetech | |
| Model Number | GACP-0825-10D |
Product Description
Specifications
800-2500mhz Dierectional Coupler, Coupling 5dB6dB7dB10dB15dB 20dB 30dB,insertion Loss<2.0dB<1.7dB<1.5dB<0.8dB <0.4dB<0.3db<0.2dbSpecifications
800-2500mhz Dierectional Coupler, Coupling 5dB6dB7dB10dB15dB 20dB 30dB,insertion Loss<2.0dB<1.7dB<1.5dB<0.8dB <0.4dB<0.3db<0.2db
RF 800-2700MHz N-Female Directional Coupler 50ohm PIM: -150dBc@2*+43dBm Power:200W.
800-2700MHz N-Female Directional Coupler
Features:
l Low Insertion Loss
l High power handing
l Small size, Low weight
l N-Female connecters
Specification:
Product Type | 6dB Coupler | 10dB Coupler | 15dB Coupler | 20dB Coupler |
Model No. | GACP 0827-6D | GACP 0827-10D | GACP 0827-15D | GACP 0827-20D |
Frequency Range | 800 – 2700MHz | |||
Coupling | 6dB | 10dB | 15dB | 20dB |
Insertion Loss | ≤1.7dB | ≤1.0dB | ≤0.4dB | ≤0.3dB |
VSWR | <1.25 | |||
PIM (IM3) | <-150dBc @+43dBm*2 | |||
Power Handling | 200W | |||
Impedance | 50Ω | |||
Connector Type | N-Female | |||
Applied Environment | Indoor/outdoor | |||
Operating Temperature | -25 to +70°C | |||
