Specifications
1. manufacturer slitting rewinding machine2. oversea engineer available paper machine rewinder
3 CE ISO certificated rewinder
PRODUCT DESCRIPTION:
ZWJK Frame-type High-speed downward Rewinder, is used for slitting the first-rolled original paper roll, rewinding it to the finished paper roll which comply with the width and tightness demand.
The machine has two types. Facing with the paper-out side, if the drive part is on the right side, then it is right-hand machine, vice versa. The customer can choose the type according to personal demand.
TECHNICAL PARAMETER:
1:trim width: 2500mm
2:paper picking up way: downward
3:GSM: 80—300g/m2
4:the max dia of original paper roll: φ1250mm
5:the max dia of finished paper roll: φ1250mm
6:working speed: 600m/min
7:supporting roll dia: φ420mm
8:machine frame center distance: 3680mm
9:supporting roll center distance: 3200mm
10:motor power: 37Kw, 415v
11: frequency Inverter: 1pc
12:slitting upper and lower circular knife 5sets
13:lower circular knife (φ250)
14:upper circular knife (pneumatic type)
15:sheet feed device 1set
16: paper unloading table 1 set
17:hydraulic pressure station 1set (with hydraulic proportion valve)
18:operation table 1set
19:outer dimension: 4130*3980*3200(mm)
20:weight: 15.5t
21: The dynamic balance speed is 800mpm
OUR FACTORY:
