PRODUCT DESCRIPTION:
ZWJK Frame-type High-speed downward Rewinder, is used for slitting the first-rolled original paper roll, rewinding it to the finished paper roll which comply with the width and tightness demand.
The machine has two types. Facing with the paper-out side, if the drive part is on the right side, then it is right-hand machine, vice versa. The customer can choose the type according to personal demand.
Technical Parameter of ZWJK 1880 frame type paper rewinder:
1. Net paper width:1880mm
2. Licking way:overfeed
3. Max.diameter of parent roll:Φ2000mm
4. Max.diameter of winding:Φ1500mm
5. Design speed:700m/min
6. Working speed:600m/min
7. Diamter of bottom roll:Φ420X2650X25mm(wall thicness),surface is sandblasted.
8. Longitudinal knife: 4 sets(cutting 5 rolls at a time)
Diameter of bed knife anxis:Φ280mm;
Bottom circular knife: Φ280mmXΦ420X92,6nos;
Top blade:Φ150XΦ90X2,6nos.
9. Active curved roll:Φ171mm,surface is chromeplated.
10. Unwinding pneumatic brake device:1set(pneumatic tire:Φ120mm,2nos).
11. Inverter motor:280-4A-22kw,Inverter:ABB
12. Brake:YWZ300/45,1set.
13. Speed reducer:ZD25;ratio:2.8,1set.
14. Oil cylinder: Lifting cylinder of hydraulic roll:Φ100X800=2nos
15. Paper forwarding cylinder:Φ80X380=2nos
16. Hydaulic unit assembly:1set,Motor power of hydraulic unit:4kw.
17. Gauge:2580mm
18. External size:4130X5380X3200mm
19. Weight:18t
20.All surfaces of roll body are chromeplated
OUR FACTORY:
