Vertical Air-floating Fine Boring Machine FT7
This machine is mainly used for boring engine’s cylinder of automobile and tractor to retreat it. It is also applicable for boring cylinder of V engine, and other mechanical part’s holes such as cylinder sleeve of single cylinder, if some suitable fixtures are equipped.
Model | FT7 |
Boring Diameter | 39-180mm |
Max. Boring Depth | 380mm |
Spindle Speed | 50-1000rpm, stepless |
Feeding Speed of Spindle | 15-60mm/min, stepless |
Spindle Rapid Rising | 100-960mm/min, stepless |
Main Motor | Power 1.1kw |
4-step basic frequency 50Hz | |
Synchronous speed 1500r/min | |
Feed Motor | 0.4kw |
Positioning Motor | 0.15kw |
Working Pressure | 0.6≤P≤1 Mpa |
Centering Range of Centering Rack
| 39-54mm |
53-82mm | |
81-155mm | |
130-200mm | |
Spindle 38mm | 39-53mm (optional) |
Spindle 52mm | 53-82mm( standard accessory) |
Spindle 80mm | 81-155mm(standard accessory) |
Spindle 120mm | 121-180mm( optional) |
Overall Dimension | 1400x930x2095mm |
Machine Weight | 1350kg |
Standard accessories: Spindle Φ 50,Spindle Φ 80 ,Parallel support A ,Parallel support B, Boring cutters
Optional accessories: Spindle Φ 38,Spindle Φ 120,Air-floating V-type cylinder fixture,Block handler
