CNC Camshaft Grinding Machine/Model MK8312C
Type: MK8312C
High machining accuracy and stable performance.
Machine adopt Germany's Siemens 840D CNC system headstock spindle rotation and wheel frame feed axis machining machining cam profile.
It can be completed in one clamping camshaft grinding.
With a single cycle, two-cycle and single cam grinding a variety of processing methods.
Circulation operation with a variety of safety interlock protection, overload.
Suitable for mass production.
Item |
MK8312C |
||
Range of Capacity |
Max. Swing diameter diameter |
125 mm |
|
Max.length of workpiece |
1000:1250:1600 mm |
||
Max. weight of workpiece |
60kg |
||
Center height |
170mm |
||
Grinding Wheel size |
600x32x305mm |
||
Maximum peripheral speed of grinding wheel |
60m/s ,80m/s |
||
Max travel of grinding wheel rack |
300 |
||
Max travel speed of grinding wheel rack |
10m/min |
||
Min feeds of grinding wheel rack |
0.001mm |
||
Max travel speed of worktable |
10mm |
||
Headstock center |
Morse 5# |
||
Headstock rotating speed |
0-200rpm |
||
Tailstock center |
Morse 4# |
||
Tailstock retractable length |
30mm |
||
Diamond rolling wheel size |
120mm |
||
Working accuracy |
Base circle size precision |
±0.02 |
|
Cam lift error |
±0.02 |
||
Lift adjacent error |
±0.02/1° |
||
Cam phase error |
±10′ |
||
Cam surface roughness |
Ra0.32μm |
||
Standard accessories :
Full set of electric equipment
Full set of cooling equipment
Wheel dresser
Open type Center rest
Machine gaskets
