Phenolic foam making machine with ISO9001:2008 and CE
- 30 Set / Sets per Month
- Tianjin
- T/T L/C
Product Details
Place of Origin: | Hebei, China | Brand Name: | xuelong | Model Number: | XL-FC1000 |
Product Description
Specifications
phenolic sandwich panel production line1. thickness of pf core sheet: 50,60,80,100,120mm
2. width of sandwich panel:1000mm
Phenolic foam(PF) sandwich panel production line with color-steel facing
Rigid polyfoam sandwich panel continuous production line is specialized equipment used for producing both the upper and lower sides are color-steel sandwich panel with core sheet is anti-combustion polyurethane, polyisocyanurate or phenolic foam. This production line is mainly applied to produce roof panels and wall panels of steel structure buildings, which could also produce other insulation foam panels by changing the upper and lower facing material. Its operation principle is rigid polyfoam raw material with a certain blending ratio sent to pouring head for mixing by metering pump on the injection machine, then uniformly injected on the lower facing. After this injection, the lower facing sheet together with upper facing sheet will by conveyed into the double-belt laminating conveyor. The injected material will be foamed and hardened into shape during its laminating and conveying process. At the end of this production line, the formed sandwich panel will be cutted into preset length by auto-tracking cutting machine.
Xuelong phenolic foam sandwich panel production line can produce the phenolic foam as core sheet and upper and lower layer are color-steel. The main technical parameters as follows,
Phenolic foam sheet core thickness :50mm,60mm,80mm,100mm,120mm;
Al-Mg-Mn alloys sheet: thickness: 0.3-1.0mm width:1000,1200mm;
Color coated steel sheet: thickness:0.5-1.0mm width: 1000,1200mm;
Effective width for the phenolic foam sandwich panel: 1000mm;
Length can be any size according to customers' requirements;
Phenolic foam density is 50-65kg/cbm.
The whole phenolic foam sandwich panel production line production speed: 1-4m/min;
Laminating conveyor length:24m;
Pouring head stirring speed :< 4500r/min;
Pouring head reciprocating speed: <1200mm/s;
Hot air circulating temperature: 60-70°C ;
Max opening height of phenolic foam sandwich panel laminating main machine: 300mm;
Installation power :147kw;
Phenolic resin reactor power: 26kw;
Electric heating system power: 54kw.
